PowerSafe – Commercial & Industrial
25
Tri-Load / Tri-Load Renewable
Quality Features
s One board with three metered sections - configurable as a power and lighting board or
power, lighting and mechanical services.
s Tri-Load renewable - power, lighting and integration of PV / wind within the distribution board,
capturing export energy data as part of the standard metering function
s Variable configuration - Where required, the mechanical services section can be incorporated
into either the power or the lighting section, creating a variable composition of each metered
section
s Pre-wired - metering elements are fully installed and programmed
s Single piece main busbars - design eliminates potential hotspots
s Modbus RS485 - Modbus RS485 communication as standard
s Single phase - can be configured for Single phase applications
s Removable side gland plates and interface gasket included
General characteristics
Tri-load is the only standard distribution board
that conveniently separates small power circuits,
lighting circuits and mechanical services loads
and provides net energy values of each load
type. Tri-load is supplied fully configured and
ready to go with the main switch pre-installed.
The metering meets the requirements of IEC
62503-21 Class 1.
Tri-Load B Type General Characteristics
IP Rating
Paint Specification
Conditional Short Circuit Rating
IP3X
RAL 7035 epoxy powder coating
25kA to BS EN 61439-3
Cable Capacities
200A Switch Disconnector
Enclosure Earth Stud
Incoming earth terminal
Incoming neutral terminal
Outgoing earth terminal
Outgoing neutral terminal
120mm
2
(M10 hole)
M8
M8
M8
25mm
2
25mm
2
