HAVELLS
Tri-Load / Tri-Load Renewable
Description
Current
(A)
Ways
3P Part No.
4P Part No.
12way TPN Type 'B' Tri-Load
Distribution Board
200
2+4+6 PSBTL246
PSBTL4P246
18way TPN Type 'B' Tri-Load
Distribution Board
200
2+6+10 PSBTL2610
PSBTL4P2610
24way TPN Type 'B' Tri-Load
Distribution Board
200
2+10+12 On Request
PSBTL21012
Description
Current
(A)
Ways
3P Part No.
4P Part No.
12way TPN Type 'B' Tri-Load MID
Distribution Board
200
2+4+6 PSBTL246MID On Request
18way TPN Type 'B' Tri-Load MID
Distribution Board
200
2+6+10 PSBTL2610MID On Request
24way TPN Type 'B' Tri-Load MID
Distribution Board
200
2+10+12 On Request
PSBTL21012MID
Description
Current
(A)
Ways
3P Part No.
4P Part No.
12way TPN Type 'B' Tri-Load
Renewable Distribution Board
200
2+4+6 PSBTL246R On Request
18way TPN Type 'B' Tri-Load
Renewable Distribution Board
200
2+6+10 PSBTL2610R On Request
24way TPN Type 'B' Tri-Load
Renewable Distribution Board
200
2+10+12 On Request
PSBTL21012R
Tri-Load Distribution Board
All Triload distribution boards are supplied with a 250A Cbi incoming device fitted. The
metering function provides separate net values of electrical parameters for three separate
groups of protective devices i.e. Power, Lighting and Mechanical Services from a single meter.
Tri-Load MID Distribution Board
Provides the same level of metering functionality as a standard Tri-Load with the added
benefit of an additional MID approved meter for tenant billing applications.
Tri-Load Renewable Distribution Board
Metering function provides separate net values of electrical parameters for two separate
group loads and a separate section for the connection of supplies from micro-generated
power i.e. Power, Lighting and export energy from Renewable sources.
