Operator Panels
TAC Xenta OP 1500
The TAC OP 1500 is a rugged PC designed for industrial applications. It is
built around an IP65 front panel with a 15” color TFT LCD screen and a
high-definition analog touch panel.
The TAC OP 1500 is used as a web client for TAC Vista Webstation, TAC
Xenta 511, or other information systems. It is compact and easy to install and
setup. No software installation is required. Once connected it is ready to run.
For user convenience, the browser start page and/or favorites can easily be
configured to suit the current installation.
TAC OP 1500 has an Ethernet port and communicates with the system over
IP networks. Adobe Acrobat Reader
®
and Microsoft Office Viewers are pre-
installed to enable users to view documents in these formats on the device.
Also, the device is prepared with the correct Java Runtime Environment for
use with TAC Xenta 511. The TAC OP 1500 is delivered with a power supply.
FUNCTIONAL FEATURES
•
Rugged 15” LCD display
•
High resolution touch screen
•
Easy installation
•
Built-in reader for pdf, doc, xls
and ppt.
•
JVM (Java Virtual Machine)
installed
•
Powered by a 24V AC/DC
converter (included)
SPECIFICATIONS
Supply voltage . . . . . . . . . . . . . . . . 24 V DC (19.2 – 28.8 V DC)
Power consumption . . . . . . . . . . . . max. 80 W
Transformer sizing . . . . . . . . . . . . . 80 VA
Ambient temperature
Storage. . . . . . . . . . . . . . . . . . . . . . -10 °C to +60 °C (14 °F to +140°F)
Operation . . . . . . . . . . . . . . . . . . . 0 °C to +45 °C (32 °F to +113 °F)
Humidity . . . . . . . . . . . . . . . . . . . . max. 85% RH non-condensing
Mechanical
Enclosure . . . . . . . . . . . . . . . . . . . . Hardened steel
Enclosure rating, front panel. . . . . . P 65
Dimensions. . . . . . . . . . . . . . . . . . . 395 X 294 X 67mm (outer frame)
(15.6” x 11.6” x 2.6)
Weight . . . . . . . . . . . . . . . . . . . . . . 6.0 kg (13.2 lbs)
Built-in I/O ports
Ethernet TCP/IP . . . . . . . . . . . . . . . RJ45 10BASE-T/100BASE-TX link
DESCRIPTION
0-073-0924-0 TAC OP 1500 incl Power Supply
