Air Handling Controllers
TAC 2411, 2412 and 2413
The TAC 2000 family now includes a series of advanced system solutions for
air handling. They are complete solutions for complete control, monitoring
and supervision of air handling units in buildings.
The following controllers are available:
•
TAC 2411 offers a rational and efficient solution to air handling where the
heating coil controls the room or supply air temperature.
•
TAC 2412 has extended functionality. The room or supply air
temperature is controlled in sequence using the heating coil and heat
recovery.
•
TAC 2413 is the most advanced controller. The room or supply air tem-
perature is controlled in sequence using the heating coil, heat recovery
and the cooling coil.
SPECIFICATIONS
Power supply . . . . . . . . . . . . . . . 24 V AC ±20 %, 50–60 Hz
Power consumption . . . . . . . . . . 3 W
Ambient Temperature
Storage. . . . . . . . . . . . . . . . . . . . –20 °C to +50 °C (–4 °F to +122 °F)
Operation . . . . . . . . . . . . . . . . . 0 °C to +50 °C (32 °F to +122 °F)
Humidity . . . . . . . . . . . . . . . . . . max. 90% RH non-condensing
Real Time Clock
Accuracy . . . . . . . . . . . . . . . . . . 16 minutes/year at +25 °C (77°F)
Memory backup. . . . . . . . . . . . . 48 hours
Color . . . . . . . . . . . . . . . . . . . . . grey/red/transparent
Weight . . . . . . . . . . . . . . . . . . . . 0.7 kg
Dimensions B x H x D . . . . . . . . 144 x 96 x 96mm
(5.7”x 3.8”x 3.8”)
Material . . . . . . . . . . . . . . . . . . . ABS/PC plastic
Enclosure rating . . . . . . . . . . . . . IP 40
DESCRIPTION
200-3101-000 TAC 2411 Swedish/Finnish
200-3103-000 TAC 2411 Danish
200-3051-000 TAC 2412 Swedish/Finnish
200-3053-000 TAC 2412 Danish
200-3001-000 TAC 2413 Swedish/Finnish/English
200-3003-000 TAC 2413 Danish
ACCESSORIES
0-073-0904-0 TAC Xenta OP mounting kit panel
FUNCTIONAL FEATURES
•
Easy to operate with clear
symbols
•
Complete solution in one box
•
Built-in Time Scheduling:
weekly and yearly programs
•
Alarm handling. A and B alarms
•
Pump Control energy savings
•
Outdoor compensation by
adjustable curve
