TAC Xenta
Network Infrastructure
TAC Network infrastructure product line enables seamless integration
between IP network, field buses and telephone lines. It gives a variety of
methods to connect a PC to the network. It includes a gateway for I/Net to
be integrated into TAC Vista. It allows for optimized L
ON
W
ORKS
®
network
design and structure also using different types of routers, both for LON to
LON and IP to LON connections.
L
ON
W
ORKS
®
network quality is improved using terminators, and can be ex-
tended via repeaters or routers. Problems on the network are detected using
the Protocol analyzer.
The TAC Network infrastructure includes all necessary components to design
a scalable and durable L
ON
W
ORKS
®
network.
L-VIS is a high resolution touch-screeen display used for graphical presenta-
tion and control locally on the network
• Connect the PC to the network
via telephone/IP/L
ON
W
ORKS
®
adapters
• L
ON
W
ORKS
®
adapters connect to
PC via USB/Serial port/PCI/IP
• Plug and Play network design
using intelligent L
ON
W
ORKS
®
routers and switches
• Easy to use IP to LonWorks
routers make the IP network
the natural backbone in the
L
ON
W
ORKS
®
network
• Network trouble shooting via
the LPA
• I/Net integration to TAC Vista
via Xenta 911
• High resolution local graphics in
L-VIS
Communication Modules
Function
Web Server
LonTalk Adaptor /
Telephone Line
LonTalk Adaptor /
Ethernet Network
LonWorks Interface /
MODBUS, BACnet etc.
TAC Xenta 511
T
T
TAC Xenta 901
T
TAC Xenta 911
T
T
TAC Xenta 913
T
