23 Moulded Case Breakers 0115
ABB Low Voltage
Fixed Pattern Circuit Breaker
Supplied as standard with front bar terminals for busbar - for other terminals see
accessories section
Ratings @ 400V
Icu
Ics
XT4N
36kA
100%
XT4S
50kA
100%
XT4H
70kA
100%
Power distribution MCCBs
Type Tmax XT4 - N, S, H thermomagnetic & magnetic only
Model
Current [A]
Product Hierarchy 3000009
Order Code
Ith/In
I3
%N
3 Pole
4 Pole
XT4N TMD
XT4N160R20
300A
100
1SDA068080R1
1SDA068094R1
XT4N160R32
320A
100
1SDA068082R1
1SDA068096R1
XT4N TMA
XT4N160R50
500A
100
1SDA068084R1
1SDA068098R1
XT4N160R80
800A
100
1SDA068086R1
1SDA068100R1
XT4N160R100
1000A
100
1SDA068087R1
1SDA068101R1
XT4N160R125
1250A
100
1SDA068088R1
1SDA068107R1
XT4N160R160
1600A
100
1SDA068089R1
1SDA068108R1
XT4N250R200
2000A
100
1SDA068090R1
1SDA068109R1
XT4N250R250
2500A
100
1SDA068092R1
1SDA068111R1
XT4S TMD
XT4S160R20
300A
100
1SDA068300R1
1SDA068314R1
XT4S160R32
320A
100
1SDA068302R1
1SDA068316R1
XT4S TMA
XT4S160R50
500A
100
1SDA068304R1
1SDA068318R1
XT4S160R80
800A
100
1SDA068306R1
1SDA068320R1
XT4S160R100
1000A
100
1SDA068307R1
1SDA068321R1
XT4S160R125
1250A
100
1SDA068308R1
1SDA068327R1
XT4S160R160
1600A
100
1SDA068309R1
1SDA068328R1
XT4S250R200
2000A
100
1SDA068310R1
1SDA068329R1
XT4S250R250
2500A
100
1SDA068312R1
1SDA068331R1
XT4H TMD
XT4H160R20
300A
100
1SDA068333R1
1SDA068347R1
XT4H160R32
320A
100
1SDA068335R1
1SDA068349R1
XT4H TMA
XT4H160R50
500A
100
1SDA068337R1
1SDA068351R1
XT4H160R80
800A
100
1SDA068339R1
1SDA068353R1
XT4H160R100
1000A
100
1SDA068340R1
1SDA068354R1
XT4H160R125
1250A
100
1SDA068341R1
1SDA068360R1
XT4H160R160
1600A
100
1SDA068342R1
1SDA068361R1
XT4H250R200
2000A
100
1SDA068343R1
1SDA068362R1
XT4H250R250
2500A
100
1SDA068345R1
1SDA068364R1
Thermomagnetic TMA Magnetic Only TMD
