26 Moulded Case Breakers 0115
ABB Low Voltage
Fixed Pattern Circuit Breaker
Supplied as standard with front bar terminals for busbar - for other terminals see
accessories section
Ratings @ 400V
Icu
Ics
T6N
36kA
100%
T6S
50kA
100%
T6H
70kA
100%
Thermomagnetic TMA
Product Hierarchy 3000006
Order Code
Model
Current [A]
Ith/In
I3
%N
3 Pole
4 Pole
T6N TMA
T6N630R630
6300A
100
1SDA060202R1
1SDA060210R1
T6N800R800
8000A
100
1SDA060214R1
1SDA060222R1
T6S TMA
T6S630R630
6300A
100
1SDA060204R1
1SDA060211R1
T6S800R800
8000A
100
1SDA060216R1
1SDA060223R1
T6H TMA
T6H630R630
6300A
100
1SDA060206R1
1SDA060212R1
T6H800R800
8000A
100
1SDA060218R1
1SDA060224R1
Power distribution MCCBs
Type Tmax T6 - N, S, H, L thermomagnetic electronic release
Electronic Release
Product Hierarchy 3000006
Order Code
Model
Type
In
3 Pole
4 Pole
T6N LS/I
T6N630 PR221DS-LS/I
630A
1SDA060226R1
1SDA060231R1
T6N800 PR221DS-LS/I
800A
1SDA060268R1
1SDA060273R1
T6N P-LSI
T6N630 PR222DS/P-LSI
630A
1SDA060228R1
1SDA060233R1
T6N800 PR222DS/P-LSI
800A
1SDA060270R1
1SDA060275R1
T6S LS/I
T6S630 PR221DS-LS/I
630A
1SDA060236R1
1SDA060243R1
T6S800 PR221DS-LS/I
800A
1SDA060278R1
1SDA060285R1
T6S P-LSI
T6S630 PR222DS/P-LSI
630A
1SDA060238R1
1SDA060243R1
T6S800 PR222DS/P-LSI
800A
1SDA060280R1
1SDA060285R1
T6H LS/I
T6H630 PR221DS-LS/I
630A
1SDA060246R1
1SDA060251R1
8T6H00 PR221DS-LS/I
800A
1SDA060289R1
1SDA060294R1
T6H P-LSI
T6H630 PR222DS/P-LSI
630A
1SDA060248R1
1SDA060253R1
T6H800 PR222DS/P-LSI
800A
1SDA060291R1
1SDA060296R1
