22 Moulded Case Breakers 0115
ABB Low Voltage
Fixed Pattern Circuit Breaker
Supplied as standard with front bar terminals for busbar - for other terminals see
accessories section
Ratings @ 400V
Icu
Ics
XT3N
36kA
100%
XT3S
50kA
100%
XT3H
70kA
100%
Thermomagnetic TMA
Model
Current [A]
Product Hierarchy 3000009
Order Code
Ith/In
I3
3 Pole
4 Pole
XT3N
XT3N160R63
630A
1SDA068053R1
1SDA068060R1
XT3N160R80
800A
1SDA068054R1
1SDA068061R1
XT3N160R100
1000A
1SDA068055R1
1SDA068062R1
XT3N160R125
1250A
1SDA068056R1
1SDA068067R1
XT3N160R160
1600A
1SDA068057R1
1SDA068068R1
XT3N160R200
2000A
1SDA068058R1
1SDA068069R1
XT3N160R250
2500A
1SDA068059R1
1SDA068070R1
XT3S
XT3S160R63
630A
1SDA068215R1
1SDA068222R1
XT3S160R80
800A
1SDA068216R1
1SDA068223R1
XT3S160R100
1000A
1SDA068217R1
1SDA068224R1
XT3S160R125
1250A
1SDA068221R1
1SDA068229R1
XT3S160R160
1600A
1SDA068219R1
1SDA068230R1
XT3S160R200
2000A
1SDA068220R1
1SDA068231R1
XT3S160R250
2500A
1SDA068221R1
1SDA068232R1
Power distribution MCCBs
Type Tmax XT3 - N, S thermomagnetic & magnetic only
Electronic Relaease
Product Hierarchy 3000006
Order Code
Model
Type
In
3 Pole
4 Pole
XT2N
XT2N160 Ekip LS/I
63A
1SDA067056R1
1SDA067092R1
XT2N160 Ekip LS/I
100A
1SDA067057R1
1SDA067093R1
XT2N160 Ekip LS/I
160A
1SDA067058R1
1SDA067095R1
XT2S
XT2S160 Ekip LS/I
63A
1SDA067802R1
1SDA067835R1
XT2S160 Ekip LS/I
100A
1SDA067803R1
1SDA067836R1
XT2S160 Ekip LS/I
160A
1SDA067804R1
1SDA067838R1
XT2H
XT2H160 Ekip LS/I
63A
1SDA067859R1
1SDA067892R1
XT2H160 Ekip LS/I
100A
1SDA067860R1
1SDA067893R1
XT2H160 Ekip LS/I
160A
1SDA067861R1
1SDA067895R1
