Raised Floor Boxes
Standard depth 83mm
Supplied with dividers to create 3 or 4 compartment box
Two earth fixing points for flexible positioning of sockets
3mm deep medium load plate
Steel sub-frame option for heavy traffic and fine adjustment to
allow for uneven flooring
Supplied with two snap-in cable retainers/guides
Grey trim as standard
Cut-out within lid for carpet or carpet tiles up to 6mm
Reversible lid
Supplied with metal screws to attach trim to box for a secure fix
Fixings are pre-punched for quick and easy installation
Barrel lock option available for extra security
RCD option
Self closing lid for extra safety and security
Pre-wired option available with MT32 Connectors
Heavy duty steel galvanized conduit (BS EN 61386-
23:2004+A11:2010)
Product information
Other options
Steel lid & trim option for even greater strength and durability
Lid available separately
Replacement cable flap available separately
Replacement screw pack available separately
4 compartment standard floor box
(terminal) 357 x 257 x 83mm
code description pack
UM5010
1 x 2 gang Std 1
UM5020
2 x 2 gang Std 1
UM5030
3 x 2 gang Std 1
UM5110
1 x 2 gang CE 1
UM5120
2 x 2 gang CE 1
UM5130
3 x 2 gang CE 1
3 Compartment standard floor box
(through) 357 x 257 x 83mm
code description pack
UM5210
1 x 2 gang Std 1
UM5220
2 x 2 gang Std 1
UM5230
3 x 2 gang Std 1
UM5211
1 x 2 gang CE 1
UM5221
2 x 2 gang CE 1
UM5231
3 x 2 gang CE 1
3 compartment standard floor box
(terminal) 357 x 257 x 83mm
code description pack
UM1010
1 x 2 gang Std 1
UM1020
2 x 2 gang Std 1
UM1030
3 x 2 gang Std 1
UM1110
1 x 2 gang CE 1
UM1120
2 x 2 gang CE 1
UM1130
3 x 2 gang CE 1
4 Compartment standard floor box
(through) 357 x 257 x 83mm
code description pack
UM5610
1 x 2 gang Std 1
UM5620
2 x 2 gang Std 1
UM5630
3 x 2 gang Std 1
UM5611
1 x 2 gang CE 1
UM5621
2 x 2 gang CE 1
UM5631
3 x 2 gang CE 1
Tap-off
• To MT32 connector
code length rating pack
UN8113
3m 32Amp unfused 1
UN8115
5m 32Amp unfused 1
UN8123
3m 13Amp fused 1
UN8125
5m 13Amp fused 1
Tap-off
• To MT32 connector
code length rating pack
UN8213
3m 32Amp unfused 1
UN8215
5m 32Amp unfused 1
UN8223
3m 13Amp fused 1
UN8225
5m 13Amp fused 1
