7 / 24
07
code description length pack
UN5192 Std Mk1 to Mk2 1.2m 1
UN5292 CE Mk1 to Mk2 1.2m 1
UN5194 Std Mk1 to Mk2 2.4m 1
UN5294 CE Mk1 to Mk2 2.4m 1
Feed unit
Female
Pack 1
Interlink
Length 1.2m
Pack 1
Interlink
Length 2.4m
Pack 1
Tap–off units
Unfused 32Amp
Length 3m
Pack 1
Tap–off units
Fused 13Amp
Length 3m
Pack 1
Tap–off units
Unfused 32Amp
Length 5m
Pack 1
Tap–off units
Fused 13Amp
Length 5m
Pack
1
UN5202 UN5204 UN7213 UN7223 UN7215 UN7225
Standard
Rated current 63Amp
Low Noise (CE)
Rated current 63Amp
UN3200
Other configurations of tap-off units including fuse options are available
on request.
All tap-off units comply with 17th Edition Wiring Regulations
Section 543 (High Integrity Earthing).
Total run
in metres
Track lengths required
3.6
3.6
4.2
1.8
2.4
4.8
2.4
2.4
5.4
3.6
1.8
6.0
3.6
2.4
6.6
2.4
2.4
1.8
7.2
3.6
3.6
7.8
3.6
2.4
1.8
8.4
3.6
3.6
1.2
9.0
3.6
3.6
1.8
9.6
3.6
3.6
2.4
10.2
3.6
3.6
1.8
1.2
10.8
3.6
3.6
3.6
11.4
3.6
3.6
2.4
1.8
12.0
3.6
3.6
3.6
1.2
Powertrack – run length component chart
To determine the number and size of track required for a given area, select your total run length (in metres) from the left hand column, then find
the correct track combinations along that row.
Mark 1 to Mark 2 Interlink
(for connecting our old style Mark 1 system to this new system).
Total run
in metres
Track lengths required
12.6
3.6
3.6
3.6
1.8
13.2
3.6
3.6
3.6
2.4
13.8
3.6 3.6
3.6
1.8
1.2
14.4
3.6 3.6
3.6
3.6
15.0
3.6 3.6
3.6
2.4
1.8
15.6
3.6 3.6
3.6
3.6
1.2
16.2
3.6 3.6
3.6
3.6
1.8
16.8
3.6 3.6
3.6
3.6
2.4
17.4
3.6 3.6
3.6
3.6
1.8
1.2
18.0
3.6 3.6
3.6
3.6
3.6
18.6
3.6 3.6
3.6
3.6
2.4
1.8
19.2
3.6 3.6
3.6
3.6
3.6
1.2
19.8
3.6 3.6
3.6
3.6
3.6
1.8
20.4
3.6 3.6
3.6
3.6
3.6
2.4
All images shown are for illustration purposes only and products may differ slightly from those shown.
When using a Mark 1 to Mark 2 Interlink the system will only comply
to the Mark 1 specification, BS EN 60439-1:1999 & BS EN 60439-
2:2000
UN3100 UN5102 UN5104 UN7113 UN7123 UN7115 UN7125
