PVC-U perimeter trunking systems
| 281
Cable capacity chart
Compartment 1 Compartment 2 Compartment 3 Compartment 4
No box With box No box With box No box With box
No box
Data cable: Ø6.0mm²
Sterling Profile 1
20
-
61
22
20
-
-
Sterling Profile 2
20
-
61
22
25
-
-
Sterling Profile 3
25
-
61
22
25
-
-
Sterling Curve Profile 1
19
-
61
22
19
-
-
Sterling Curve Profile 2
19
-
61
22
25
-
-
Sterling Profile 4
20
-
61
22
59
20
-
Sterling Profile 5
25
-
61
22
59
20
-
Sterling Profile 6
59
20
61
22
59
20
-
Sterling Profile 11
20
-
61
22
57
17
20
Sterling Profile 12
20
-
61
22
57
17
23
Sterling Profile 13
23
-
61
22
57
17
23
Data cable: Ø6.5mm²
Sterling Profile 1
18
-
54
19
18
-
-
Sterling Profile 2
18
-
54
19
22
-
-
Sterling Profile 3
22
-
54
19
22
-
-
Sterling Curve Profile 1
16
-
54
19
16
-
-
Sterling Curve Profile 2
16
-
54
19
22
-
-
Sterling Profile 4
18
-
54
19
52
17
-
Sterling Profile 5
22
-
54
19
52
17
-
Sterling Profile 6
52
17
54
19
52
17
-
Sterling Profile 11
18
-
54
19
50
15
18
Sterling Profile 12
18
-
54
19
50
15
20
Sterling Profile 13
20
-
54
19
50
15
20
Data cable: Ø7.0mm²
Sterling Profile 1
15
-
45
16
15
-
-
Sterling Profile 2
15
-
45
16
18
-
-
Sterling Profile 3
18
-
45
16
18
-
-
Sterling Curve Profile 1
14
-
45
16
14
-
-
Sterling Curve Profile 2
14
-
45
16
18
-
-
Sterling Profile 4
15
-
45
16
43
14
-
Sterling Profile 5
18
-
45
16
43
14
-
Sterling Profile 6
43
14
45
16
43
14
-
Sterling Profile 11
15
-
45
16
42
13
15
Sterling Profile 12
15
-
45
16
42
13
17
Sterling Profile 13
17
-
45
16
42
13
17
Data cable: Ø8.4mm²
Sterling Profile 1
10
-
31
11
10
-
-
Sterling Profile 2
10
-
31
11
13
-
-
Sterling Profile 3
13
-
31
11
13
-
-
Sterling Curve Profile 1
10
-
31
11
10
-
-
Sterling Curve Profile 2
10
-
31
11
13
-
-
Sterling Profile 4
10
-
31
11
30
10
-
Sterling Profile 5
13
-
31
11
30
10
-
Sterling Profile 6
30
10
31
11
30
10
-
Sterling Profile 11
10
-
31
11
29
9
10
Sterling Profile 12
10
-
31
11
29
9
12
Sterling Profile 13
12
-
31
11
29
9
12
