These figures are based on Marshall-Tufflex trade list price (for MT Supertube) and quoted wholesaler prices (for galvanised steel conduit) as at 22nd April 2016.
Galvanised steel conduit
MT Supertube coiled conduit
Material Cost
£2.04 per metre
+ fittings = £224
Material Cost
£2.62 per metre
+ fittings = £274.95
Labour @ 30 mins / metre
2 metres / hour
Labour @ 10 mins / metre
6 metres / hour
50 hours @ £30
£1,500
16.67 hours @ £30
£500
Galvanised steel
overall costs
£1,724
MT Supertube
overall costs
£774.95
The savings on this job amounts to £949.05 - 55% cheaper than galvanised steel.
Contractor cost and labour saving example (based on contractor purchase price)
Costs calculated on using 100m of 20mm conduit with 8 off 90° bends and estimated manpower costs of £30 per hour.
MT Supertube LSOH Conduit: A time saving alternative to steel conduit
MT Supertube is a three-layer, heavy gauge, impact-resistant conduit giving excellent EMI capabilities. Available with steel or polycarbonate
fittings, MT Supertube is manufactured to comply with BS EN 50086.
•
LSOH Polyethylene-coated aluminium
•
Can be formed by hand and no bending spring is required
•
No special tools necessary
•
MT Supertube FR Plus version is fire tested in accordance
with, and meets criteria for, Category ‘-EQ/I’ of the London
Underground Limited Engineering Standard 2-01001-002:Issue
A1:December 2003
Page
220
Cable management for transport and industrial environments
GRP vs. Steel
GRP is 40% lighter
Completely corrosion resistant. No rusting even when in contact with salt spray, H25, acid built up from exhaust gases, or brake dust along roads and railways
Fast installation with fewer fasteners
Easy to cut and drill
Slow rate of heat transfer
Earthing not required
Antimagnetic and therefore resistant to electromagnetic pulses
Lower life cycle cost
GRP cable management systems
Glass Reinforced Polyester (GRP) cable management systems are well suited
to aggressive environments, such as extreme weather or high temperatures.
The systems are extremely robust, considerably lighter than traditional metal
systems, and have excellent resistance against fire and corrosion resulting
in a very long life span. GRP systems have a large cable capacity, and offer
fast and flexible installation solutions, with the ability of on-site assembly
and configuration. Marshall-Tufflex can offer a wide range of GRP systems
including trays, ladders, ground ducts, troughing, accessories and fittings,
fixings and supports.
•
Large cable capacity
•
No need for painting means low maintenance costs
•
Self extinguishing, without toxic fumes
•
Zero Halogen
•
Resistant to temperatures from -80° to +130°
•
Excellent cable protection
