PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
146 |
XL Trunking 201 to 203
†
XL 202 trunking flat tees
Where profles have one angled cover and one square
cover, as with XL 202, it is possible to create a tee by
changing the top or bottom cover so that covers to
match the profle of the trunking. For example:
• Upward tee – select XL 201 tee remove the
angled bottom cover and replace with square cover.
• Downward tee – select XL 203 tee remove the square
top cover and replace with angled cover.
3 Compartment
XL 201
220 x 65mm
Base unit
Pack
4 x 3m
Main compartment cover
Pack
8 x 3m
Angled cover
Pack
8 x 3m
Square cover
Pack
8 x 3m
Couplers
Pack
5
End caps
Pack
5
left or right hand
Internal bends
Pack
5
External bends
Pack
5
Flat angles
Pack
1
upward or downward
Flat tees
Pack
1
†
please refer to Flat Tee
information
ELTB200
ELTB200
ELTB200
ETL1WH
ETL1WH
ETL1WH
2 x ELAC200WH ELAC200WH
–
–
ELSC200WH 2 x ELSC200WH
EC201WH
EC202WH
EC203WH
EEC201WH EEC202LHWH
EEC202RHWH EEC203WH
EIB201WH EIB202WH EIB203WH
EXB201WH EXB202WH EXB203WH
EFA201WH EFA202UWH
EFA202DWH EFA203WH
XL 202
220 x 65mm
XL 203
220 x 65mm
EFT 201WH
†
EFT203WH
