PVC-U perimeter trunking systems
PVC-U PERIMETER TRUNKING SYSTEMS
www.marshall-tufflex.comXL Trunking 201 to 203
| 143
XL 201
size
220 x 65mm
Base unit
code
pack
ELTB200
4 x 3m
Angled cover
code
pack
ELAC200WH
8 x 3m
Main compartment cover
code
pack
ETL1WH
8 x 3m
Square cover
code
pack
ELSC200WH
8 x 3m
XL 202
size
220 x 65mm
Trunking profiles
Basic components
XL Trunking sizes 201 to 203 comprise a range of deep,
large capacity 3 compartment, segregated containment
systems. These systems can accommodate integral
lighting units.
Product information
•
220 x 65mm
•
1 full and 2 half size compartments
•
XL 201 for dado installation only
•
3 deep segregated compartments
•
Can be subdivided
•
Suitable for dado and skirting application
•
Can be fed from larger trunking systems for increased cable distribution
•
Boxes available to comply with Part M (DDA)
•
Comprehensive range of flush power and data accessories
Data information
•
Can accommodate Cat 6 data cables*
•
Adjustable data box 32-47mm
•
Screened data boxes
•
Steel screening divider available
Three deep
compartments for
extra cable capacity
Three separate covers
Dividing fllet option for
centre compartment
XL 203
size
220 x 65mm
Colour options:
Optional colours
and finishes are available but these
may be subject to minimum
quantity orders and longer lead
times. For more information
contact the Technical Team on
+44 (0)1424 856688.
*Data fittings
For Cat 6 and 6a fttings
please contact the
Technical Teamon
+44 (0)1424 856688.
Part M
For boxes that meet the
requirements of Part M
(DDA) please refer to
page 106 of this section.
Standard colour
WH
WH
: White
p286
Technical
Information
antimicrobial trunking
PAGE
107
‘Biooption’available
tospecialorder
See
page 146
for quick
reference
chart
