Invicta 3 (125A Incoming 63A Outgoing)
Description
Cat ref.
Cat ref.
Plain door
Glazed door
4 Triple Pole Ways
JK104B
1
JK104BG
1
6 Triple Pole Ways
JK106B
1
JK106BG
1
8 Triple Pole Ways
JK108B
1
JK108BG
1
12 Triple Pole Ways
JK112B
JK112BG
16 Triple Pole Ways
JK116B
JK116BG
18 Triple Pole Ways
JK118B
JK118BG
24 Triple Pole Ways
JK124B
JK124BG
¹ A JK101SE is required to provide additional incoming cable space, see page 3.17.
Invicta 3 - Amendment 3 Compliant (125A Incoming 63A Outgoing)
Full metal cover & door to comply with BS EN 61439-3 including annex ZB.
Description
Cat ref.
4 Triple Pole Ways
JK104BA3
6 Triple Pole Ways
JK106BA3
8 Triple Pole Ways
JK108BA3
12 Triple Pole Ways
JK112BA3
16 Triple Pole Ways
JK116BA3
18 Triple Pole Ways
JK118BA3
24 Triple Pole Ways
JK124BA3
16 Module DIN Rail Box
JK116EA3
¹ A JK101SE is required to provide additional incoming cable space, see page 3.17.
125A Incomer Kits (
note: these incomer kits will only fit the 125A board(s)
Description
Cat ref.
3 Pole 100A Switch Disconnector Incomer Kit (fits within distribution board)
JK11003S
4 Pole 100A Switch Disconnector Incomer Kit (fits within distribution board)
JK11004S
3 Pole 125A Switch Disconnector Incomer Kit (fits within distribution board)
JK11253S
4 Pole 125A Switch Disconnector Incomer Kit (fits within distribution board)
JK11254S
4 Pole 63A Contactor Incomer Kit includes Switch Disconnector
JK10634C
2
(fits below distribution board, 300mm high)
4 Pole 100A Contactor Incomer Kit includes Switch Disconnector
JK11004C
2
(fits below distribution board, 450mm high)
125A Direct Connection Kit (fits within distribution board)
JK11254D
4 Pole 63A 30mA RCCB Incomer Kit (fits within distribution board)
JK10634RH
4 Pole 100A 30mA RCCB Incomer Kit (fits within distribution board)
JK11004RH
4 Pole 100A 300mA RCCB Incomer Kit (fits within distribution board)
JK11004RL
4 Pole 100A 300mA Time Delayed RCCB Incomer Kit (fits within distribution board)
JK11004RLD
4 Pole 100A 100mA RCCB Incomer Kit (fits within distribution board)
JK11004RM
4 Pole 100A 100mA Time Delayed RCCB Incomer Kit (fits within distribution board)
JK11004RMD
125A 4 pole Changeover Incomer Kit
JK11254CO
2
² A 300 / 450mm space is required below the board for fitting, see page 3.44 for dimensions.
Invicta 3 125A TP&N
Distribution Boards
Surface mounted steel
enclosures.
Enclosure degree of protection:
IP3X
Enclosures are available with
plain or glazed doors.
Fully shrouded copper busbar,
rated 25kA short circuit
conditional current.
Supplied without incoming and
outgoing devices.
A Hager incomer kit must be
used.
Incoming cable sizes
125A & !00A 50mm
2
63A 25mm
2
Complies with BS EN 61439-3
Annex ZB.
For dimensions see page 3.41
For a full list of protection
devices see section 4 of this
catalogue (Protection Devices).
Invicta 3 Type B Distribution Boards
125A Incoming 63A Outgoing
JK106BG
JK106BA3
JK11003S
