General Catalogue • Protection Devices
Miniature Circuit Breakers
80 - 125A C & D Curve
Thermal Magnetic Circuit
Breakers Curves C & D
I n 80 to 125 A
These circuit breakers are
intended for the protection of the
circuits against overloads and
short circuits.
HMC C Curve
15 kA
(BS EN 60898 Part 1)
15 kA for 80 - 100 - 125 A:
BS EN 60947-2
Width 1.5 mod/pole
HMD D Curve
15 kA
(BS EN 60898 Part 1)
15 kA for 80 - 100 - 125 A:
BS EN 60947-2
Width 1.5 mod/pole
HMF C Curve
10 kA
(BS EN 60898 Part 1)
10kA for 80 - 100 - 125A:
BS EN 60947-2
width 1.5 mod/pole
These circuit breakers are
equipped with reinforced screw
cages.
A label holder is integrated under
the toggle to ensure the location
of the product.
The “OFF” position is clearly
shown by a green indicator
below the toggle.
Suitable for isolation (according
to BS EN 60947-2) the
isolation of the circuit breakers is
indicated by a green indicator on
the toggle.
These circuit breakers have
quick closing : fast and
simultaneous closing of the
contacts, independent of the
handling speed.
This increases the life of the
circuit breaker whatever the type
of load.
Nominal Voltage
230/415 V~
Calibration setting : 30 °C
(BS EN 60898 Part 1)
Insulation voltage : 500 V
Options
Auxiliary
• To visualise the state ON or
OFF of the circuit breaker,
• To ON/OFF remotely the
circuit breaker
• Locking mechanism
• Terminal covers and phase
separators
• RCD add-on blocks
Series HMC, HMD, HMF
• Mounting capability:
bistable DIN-rail latches
(2 positions) upstream and
downstream facilitate the
mounting of the circuit
breakers on the DIN-rail.
• These circuit breakers are
equipped with push terminals
to feed an auxiliary low
voltage circuit (indicating
lights, auxiliary control...)
Max. current 6A
Max. cable csa - 6 mm
2
Lockable Toggle
MCB can be locked in “Off”
position by the integrated
locking facility on the toggle.
This lock allows to insert a
2.5-3.5mm plastic cable tie
where you can fit a warning card
if necessary and allows a safer
working environment for all
personnel.
RCD Add-On Blocks
Simple, quick, adjustable and
fixed
1. Assembly
2. Connection
3. Locking
The assembly of the add-on
block is carried out very quickly
and easily. Simple and fast : it
is a Hager innovation. Add-on
blocks 125A are available in
fixed version and adjustable
version.
Model
Icc / Curve Accessories Fast-on Connection Tightening Comp. System Lockable Front Product Labelling
HMF
10kA / C Yes
No
No
Yes
Yes
HMC, HMD 15kA / C, D Yes
Yes
Yes
Yes
Yes
