Pluggable standard and digital
The advantages for you:
• Digital switching capability,
up to 24 DSI or DALI ballasts.
• Automatically detects and configures to DSI or DALI ballasts.
• Integral photocell allows for lighting control which can provide
energy savings by not operating when sufficient natural light
levels exist.
• Wide operating range to suit most commercial applications.
Allows overrun of lighting to be customised to installation.
• Available pre-wired, reduces installation time on site and
requirement for non-standard cable.
Technical data:
• Integral photocell 5 - 1000 lux
• Detection:
High sensitivity detection up to 5m diameter
Motion detection up to 7m diameter
• Time out adjustment:
2 min - 57 min with remote programmer
1 min - 1 hour with potentiometer
• Pre-wired cable:
3m 1.5mm
2
Low Smoke Zero Halogen for Relay model
3m 0.75mm
2
Low Smoke Zero Halogen for Digital model
Our range of occupancy sensors detect infra-red radiation and ambient light levels to provide simple
and cost effective means of lighting control.
The EEK range of sensors should be mounted in the centre of the group of luminaires to be controlled
and the optimum all round coverage is achieved with the unit mounted at a height of 2.5m. The
coverage for these sensors at this height is approximately 5m diameter for small movement such as
working at a desk, and 7m for larger movements such as walking.
Occupancy sensors
2
3
4
1
