General Catalogue • Protection Devices • Technical
MCCBs, Moulded Case Switches
x160
Dimensions
MCCB x160
Ech. 30%
11
97
68
15
45
130
25 25
A
25
114
111
A
(mm)
1P
24.8
2P
49.5
3P
74.5
4P
99.5
Terminal covers for extended straight connections
A
(mm)
1P
24.4
2P
49.5
3P
74.5
4P
99.5
230
A
C
B
Terminal cover for extended spreader connections
A
(mm)
3P
106.5
4P
141.5
61
A
B
A
A
A
61
