SCREED OUTLET BOX
Base Size 100 x 200 mm 200 x 200 mm 265 x 265 mm 340 x 265 mm
Number of Compartments 1 2 3 4
BASE 55-80mm CUB100UK-1 CUB200UK-2 CUB265UK-3 CUB340UK-4
80-100mm CUB100XUK-1 CUB200XUK-2 CUB265XUK-3 CUB340XUK-4
LID & FRAME 8mm RECESS CXL100-8GRY CXL200-8GRY CXL265-8GRY CXL340-8GRY
ADAPTOR PLATE SIZE N/A 200 265 340
SIDE PLATES AS STD N/A 2 X CUBP200-03 2 X CUBP265-03 2 X CUBP340-04
NO. / TYPE OF APERTURE ON SIDE PLATE 20 & 25MM CONDUIT
DIRECTLY INTO BASE UNIT
2 X PVC 60X25mm 3 X PVC 60 X 25mm 3 X PVC 90 X 35mm
OPTIONAL SIDE PLATE ADAPTORS N/A CUBP200-01 CUBP265-01 CUBP340-01
N/A CUBP200-02 CUBP265-02 CUBP340-02
N/A CUBP200-03 CUBP265-03 CUBP340-03
N/A CUBP200-04 CUBP265-04 CUBP340-04
N/A N/A CUBP265-08 CUBP340-08
JUNCTION BOX
Base Size 200 x 200 mm 265 x 265 mm 340 x 340 mm
Number of Compartments 2 3 4
BASE 55-80mm CUJ200UK CUJ265UK CUJ340UK
80-110mm CUJ200XUK CUJ265XUK CUJ340XUK
JUNCTION BOX FLY OVER INCLUDED 2 WAY 3 WAY 3 WAY
LID SUPPLIED AS STANDARD PLAIN FLAT PLAIN FLAT PLAIN FLAT
LID OPTIONS AVAILABLE
DEPTH 55-80mm 8mm RECESS CUJL200-8 CUJL265-8 CUJL340-8
12mm RECESS CUJL200-12 CUJL265-12 CUJL340-12
DEPTH 80-110mm 8mm RECESS CUJL200X-8 CUJL265X-8 CUJL340X-8
12mm RECESS CUJL200X-12 CUJL265X-12 CUJL340X-12
ADAPTOR PLATE SIZE 200 265 340
SIDE PLATES AS STANDARD 4 X CUBP200-003 4 x CUBP265-03 4 x CUBP340-04
NO. / TYPE OF APERTURE ON SIDE PLATE 2 X PVC 60 X 25MM 3 X PVC 60 X 25MM 3 X PVC 90 X 35mm
OPTIONAL SIDE PLATE ADAPTORS CUBP200-01 CUBP265-01 CUBP340-01
CUBP200-02 CUBP265-02 CUBP340-02
CUBP200-03 CUBP265-03 CUBP340-03
CUBP200-04 CUBP265-04 CUBP340-04
CUBP265-08 CUBP340-08
Screed System Product Selection Table
VERTICAL ACCESS BOX METAL DUCTING
Size 265mm 340mm
No of Compartments 2 3
VERTICAL ACCESS BOX CUV265 CUV340
COVER PLATES AS STANDARD FLUSH FLUSH
COVER PLATES OPTIONAL CUVP265 CUVP340
VERTICAL ACCESS BOX PVCu DUCTING
Size Shallow Full Access
Number of Compartments 2 3 2 3
VERTICAL ACCESS BOX SF88152 SF88153 SF88172 SF88173
COVER PLATES - OVERLAPPING SF88180 SF88181 SF88188 SF88189
COVER PLATES - FLUSH SF88176 SF88177 SF88184 SF88185
