Serviced Power Plates
Standard Part No.
Compact Part No.
Description
CXP10730*
=
CXPC10730*
=
2G 13A Switch Socket Outlet
CXP10730NS*
=
CXPC10730NS*
=
2G 13A Switch Socket Outlet Non-Standard (T Pin)
CXP10731*
=
CXPC10731*
=
2G 13A Socket Outlet
CXP10731NS*
CXPC10731NS*
2G 13A Socket Outlet Non-Standard (T Pin)
CXP10745
CXPC10745*
2G 13A Angled Socket Outlet – Power plate for CUB100
CXP10735*
CXPC10735
2G 13A 30mA Passive RCD Switch Socket Outlet**
CXP10760
2G 13A Switch Socket Outlet – Side Wired (single earth)
CXP10720
3G 13A Socket Outlet
CXP10740
CXPC10740
2G 16A 2P+E German Socket Outlet (non UK)**
* For Clean Earth wiring – add suffix ‘CE’ e.g CXP10730CE. Clean Earth switched power plates are identified with red rockers, unswitched with red sockets.
=
Plates are supplied with the MK Electric 3-pin safety shutter. Compact Plates (power and data) are for use with 200 x 200mm bases only.
If 2 socket plates or a socket plate and wave plate are to be used then only CXP10745 and CXPC10745 socket plate can be used.
**requires a 45mm wiring space.
Standard Part No.
Compact Part No.
Description
CXP20200
CXPC20200
2 x LJU6C Apertures
CXP20201*
CXPC20201*
4 x LJU6C Apertures
CXP20215
CXPC20215
4 x LJU6C Wave Apertures
CXP20205
CXPC20205
4 x Krone Apertures
CXP20301
CXPC20301
6 x LJU6C Apertures
CXP30501
CXPC30501
2 x Euro 50 x 50mm Apertures
CXP30503
1 x Euro 150 x 50mm Aperture
CXP30502
CXPC30502
2 x 45 x 45mm Apertures
CXP20500
CXPC20500
4 x ST Fibre Connector Apertures
CXP30201
CXPC30201
Blank Plate
* Data apertures are supplied as knockouts.
Additional floor restrictions apply when using these plates - see page 411 for details.
Compact Plates (power and data) are for use with 200 x 200mm bases
Standard Part No.
Description
CXP20106
1G Accessory Plate with 60.3mm fixing centres
CXP20107*
2G accessory Plate with 120.6mm fixing centres
* Recommend that a MK Electric Aspect, Edge or Logic Plus Socket Outlet is used. Can only be used in 4 module floorboxes.
Unserviced Data
Plates
Unserviced Power
Plates
Accessory Plates
Accessory plates are common to most ranges, they will fit all Cablelink Plus Single Pan, Screed and Onix Plus
™
floorboxes. Standard Plates are for use with 100 x 200mm, 265 x 265mm and 340 x 265mm floorboxes.
Standard Plates are supplied in Light Grey (LGY) finish.
CXP10730
CXP10745
CXP10735
CXP20201
CXP20215
CXP20301
CXP30201
