MK Electric Catalogue No. 49

429 / 759

Part No. Description
UK2 Hanging Bracket to suit up to ø10mm tie rod
UK2E Hanging Bracket with 50mm x 50mm Trunking Suspension Arm
UK4 Hanging Bracket with Hook
UKDC Additional Dust Cover
Please refer to Interact Overhead Power Technical – page 695, for details regards support bracket spacing and
maximum suspended load.
Tap-off Leads
Type Pin Position Current
Rating
Protection 1 metre 3 metre 5 metre Key
Code
2.5mm2 2.5mm 2 2.5mm2
SINGLE PHASE N1 L1 PE 25A UNFUSED LT12501C LT32501C LT52501C
16A FUSED LT11601C LT31601C LT51601C
N1 L2 PE 25A UNFUSED LT12502C LT32502C LT52502C
16A FUSED LT11602C LT31602C LT51602C
N1 L3 PE 25A UNFUSED LT12503C LT32503C LT52503C
16A FUSED LT11603C LT31603C LT51603C
L4 N1 PE 25A UNFUSED LT12504C LT32504C LT52504C
SINGLE PHASE +L4 L4 N1 L1 PE 25A UNFUSED LT12521C LT32521C LT52521C
L4 N1 L1(F) PE 16A FUSED LT11621C LT31621C LT51621C
L4 N1 L2 PE 25A UNFUSED LT12522C LT32522C LT52522C
L4 N1 L2(F) PE 16A FUSED LT11622C LT31622C LT51622C
L4 N1 L3 PE 25A UNFUSED LT12523C LT32523C LT52523C
L4 N1 L3(F) PE 16A FUSED LT11623C LT31623C LT51623C
ALL PHASE N1 L1 L2 L3 PE 25A UNFUSED LT12505C LT32505C LT52505C
ALL PHASE + L4 L4 N1 L1 L2 L3 PE 20A UNFUSED LT12506C LT32506C LT52506C
CIRCUIT 1 GREY PE1 N1 L1 25A UNFUSED LT12501GRY LT32501GRY LT52501GRY
16A FUSED LT11601GRY LT31601GRY LT51601GRY
CIRCUIT 2 GREY N2 L2 PE2 16A FUSED LT11625GRY LT31625GRY LT51625GRY
25A UNFUSED LT12525GRY LT32525GRY LT52525GRY
DUAL GREY PE1 N1 L1 N2 L2 PE2 20A UNFUSED LT12526GRY LT32526GRY LT52526GRY
(F) = Fused.
LSF Cable is supplied as standard. For PVC cable replace suffix ‘C’ with suffix ‘PVC’. For Dual Grey system simply add suffix ‘PVC’. Suffix must be added when ordering.
Polarity of tap-offs are configured to enable L4 to be used as a continuous conductor for Emergency Line.
When using tap-offs ensure that the line is protected by an appropriately rated protective device.
Key codes shown are from the perspective of the powertrack socket with the keycode in the top right corner.
The tap-off key code will be a mirror image when viewed from underneath.
Other Components
MK Electric Catalogue 429
OVERHEAD
SYSTEMS
Technical Hotline
+44 (0)1268 563720 Interact Overhead
Power
