SENTRY
RANGE INTRODUCTION
The Sentry range of Consumer
Units from MK Electric has
been stylishly designed to
blend in with its environment.
The curved lines and slim-line
appearance mean it won’t look
out of place when installed in
hallways, lounges or kitchens
of new properties.
The expanded range includes a 21-module unit
for larger installations and also a 4-module unit to
cater for small one-off installations and extensions
to existing ones.
The MK Electric Design Service offers a pre-
assembly service for custom built boards with all
devices fitted, busbars cut and fitted with devices,
live and neutral cables terminated.
SUPPORTS 17TH EDITION AMENDMENT 3 COMPLIANCE
Full range of products to support compliance with the 17th Edition Amendment 3
of the Wiring Regulations, including Full Metal non-combustible enclosures for
Consumer Units.
MK ELECTRIC DESIGN SERVICE FOR PRE-ASSEMBLED CONSUMER UNITS
Save time and money by specifying project requirements through the MK Electric
Design Service. Pre-assembled custom built boards, with all devices pre-fitted
with busbars and cables are available to suit any installation.
FLOATING BUSBAR SYSTEM
Gives maximum installation flexibility.
BROAD SELECTION OF PRE-ASSEMBLED SPLIT LOAD UNITS AVAILABLE
Suits a variety of applications and saves installation time.
HOW TO SPECIFY
A metal range of consumer unit and accessories (Switch’s MCB’s, RCD’s &
RCBO’s) designed to comply to the 17th Edition Amendment 3 of the wiring
regulations (BS 7671:2008). Consumer unit doors must be top hinged to ensure
the door is closed when the unit is not in use. The base, lid & door of the
consumer unit must be earthed to provide safe operation at all times. A floating
busbar system to be employed to ensure maximum installation flexibility and
acceptance of control devices. All consumer units must have a curved door to
prevent dust collection and offer a unobtrusive appearance that blends into the
environment. Backed out captive screws, removable DIN rails and sufficient wiring
space are required to ensure ease of installation and maintenance.
