COMMERCIAL & INDUSTRIAL TRUNKING
13
PLAIN INTERIOR FITTINGS
EDGE ELBOW INSIDE COVER
EEI 1 WHI
75 x 38 TC1
5
EEI 3 WHI
75 x 75 TC3
5
EEI 4 WHI
100 x 100 TC4
2
EEI 5 WHI
100 x 50 TC5
5
EEI 11 WHI 75 x 50 TC11
5
EEI 50 WHI 50 x 50 TC50
5
EDGE ELBOW OUTSIDE COVER
EEO 1 WHI 75 x 38 TC1
5
EEO 3 WHI 75 x 75 TC3
5
EEO 4 WHI 100 x 100 TC4
2
EEO 5 WHI 100 x 50 TC5
5
EEO 11 WHI 75 x 50 TC11
5
EEO 50 WHI 50 x 50 TC50
5
EDGE TEE INSIDE COVER
ETI 1 WHI
75 x 38 TC1
2
ETI 3 WHI
75 x 75 TC3
2
ETI 4 WHI
100 x 100 TC4
2
ETI 5 WHI
100 x 50 TC5
2
ETI 11 WHI 75 x 50 TC11
2
ETI 50 WHI 50 x 50 TC50
2
EDGE TEE OUTSIDE COVER
ETO 1 WHI 75 x 38 TC1
2
ETO 3 WHI 75 x 75 TC3
2
ETO 4 WHI 100 x 100 TC4
2
ETO 5 WHI 100 x 50 TC5
2
ETO 11 WHI 75 x 50 TC11
2
ETO 50 WHI 50 x 50 TC50
2
Ref. No.
Size mm Trunking Pack
Ref.
PLAIN INTERIOR
ACCESSORIES
PVC DIVIDING ANGLES
GASA 2545 WHI* 25 x 45mm 12m
GASA 3838 WHI
†
34 x 34mm 12m
GA 2525 WHI
25 x 25mm 12m
GA 2545 WHI
25 x 45mm 12m
GA 3838 WHI
34 x 34mm 12m
Ref. No.
Size
Pack
DIVIDED INTERIOR
INDUSTRIAL TRUNKING
A range of self-adhesive dividing angles allows for on-site
installation of dividers. Using self-adhesive angles allows
for greater versatility of divisions to be produced, better
suited to actual requirements.
FLAT ELBOW
FE 1 WHI
75 x 38 TC1
2
FE 3 WHI
75 x 75 TC3
2
FE 4 WHI
100 x 100 TC4
2
FE 5 WHI
100 x 50 TC5
2
FE 11 WHI 75 x 50 TC11
2
FE 50 WHI 50 x 50 TC50
2
FLAT TEE
FT 1 WHI
75 x 38 TC1
2
FT 3 WHI
75 x 75 TC3
2
FT 4 WHI
100 x 100 TC4
2
FT 5 WHI
100 x 50 TC5
2
FT 11 WHI 75 x 50 TC11
2
FT 50 WHI 50 x 50 TC50
2
END CAPS
EC 1 WHI
75 x 38 TC1
10
EC 3 WHI
75 x 75 TC3
10
EC 4 WHI
100 x 100 TC4
10
EC 5 WHI
100 x 50 TC5
10
EC 11 WHI 75 x 50 TC11
10
EC 50 WHI 50 x 50 TC50
10
INTERNAL CONNECTOR
IC 1 WHI
75 x 38 TC1
10
IC 3 WHI
75 x 75 TC3
10
IC 4 WHI
100 x 100 TC4
10
IC 5 WHI
100 x 50 TC5
10
IC 11 WHI 75 x 50 TC11
10
IC 50 WHI 50 x 50 TC50
10
Ref. No.
Size mm Trunking Pack
Ref.
SINGLE SHROUD BOX
TOB21 WHI 60.3mm (TC5)
25
(TC10)
25mm deep
TWIN SHROUD BOX
TOB22 WHI 120.6mm (TC5)
10
(TC10)
25mm deep
Ref. No.
Size
Use with Pack
* GASA 2545 is a 25 x 45mm angle, for use in TC5
(100 x 50mm) trunking. The adhesive is on the 25mm
face. Three GASA angles will produce four compartment
trunking.
†
GASA 3838 is a 34 x 34mm angle, for use in TC1
(75 x 38mm) trunking. Two GASA angles will produce
three compartment trunking.
