perimeter and distribution
|
cable management
13
Prestige
3
D
Antibac Blue
EXTERNAL CORNER
External Corners accommodate +/- 5 degree
irregularities in the squareness of a corner. Corners
come ready assembled to click into place, and offset
side splits hide the effect of the split line for aesthetics.
FLAT TEES AND ANGLES
The ingenuity of the patented tee design allows a variety of
cable drop permutations. The tee’s bridge can be "tted in
two positions increasing the versatility of cable runs whilst
maintaining the correct segregation and Cat 5e, 6 and 7
compliance. Screw "xing hole locations have a protective
shroud to prevent the cha"ng of cables. Both the Flat Angle
and Tee compartment divider walls are curved (Cat 5e, 6
and 7 compliant) to allow data cables to lay in with no loss
of capacity. The covers are one piece and clip securely
into place, and the base is also a single moulded item,
giving more strength than fabrication. Joint covers are not
required where the tee/angle meets the trunking as the
moulded covers now overlap the junction.
TRUNKING HINGE LIDS
A two stage location gives a hinge effect,
enabling cables to be supported by the trunking
cover during the installation. Cover design
avoids dust traps and makes cleaning easier,
and continues the aesthetics of the trunking.
UNIQUE FLUORESCENCE
For complete customer con"dence,
Prestige 3D Antibac Blue features a
patent pending !uorescent additive which
glows bright blue under a UV light, unlike
standard PVCu which glows dull purple.
DATA SWEEP
The unique patented Data Sweep provides Cat 5e, 6 and
7 data cabling compliance, with no loss of capacity
and without the need for bulky, protruding corner
covers.
ELECTROMAGNETIC
INTERFERENCE
Additional data cable/
signal protection is
provided by "tting
screening divider VP30.
CHOICE OF TWO
PROFILES
Available in Dado and
Skirting pro"les to suit
most installations.
STYLING LINES
All "ttings are moulded
with styling lines for
aesthetic continuity.
Prestige 3D
Prestige 3D Antibac Blue
