cable management
|
perimeter and distribution
www.mkelectric.co.uk12
Prestige
3
D
Antibac Blue
INTERNAL CORNER
Designed to accommodate irregularities in the
squareness of the corner with a +/- 5 degrees
!exibility range. The centre split gives maximum
adjustment. Covers are radiused and compatible
with Cat 5e, 6 and 7 data cabling requirements.
PRE-PUNCHED BASES
Wall "xing is simpli"ed by the
inclusion of pre-punched oval
holes at 100mm intervals, ensures
no drilling is required.
BACK BOXES
The 1 and 2 gang 35mm and 45mm deep back boxes,
3 gang 45mm deep back box and 1 and 2 gang
40mm frames ensure Cat 5e, 6 and 7 compliance
and ease of connection to power and data devices.
The open top/bottom allows unhindered tool free
cable entry, through the trunking compartment
divider knockout. The back box can slide to align
with appropriate knockout (see technical pages for
restrictions on use).
END CAPS
Neatly "nishes runs
of trunking. (Moulding
provides internal location
for extra security from
optional screw "xing).
SCREW FIXING KIT
Where higher security is required,
e.g. schools, all "tting covers can be
secured using the Screw Fixing Kit.
The Screw Fixing Kit is self-locating
on the styling line of the system and
has a cover to hide the screw head.
DIVIDER KNOCKOUTS
Wiring is also made easy
with 50 x 21mm knockouts
at 100mm intervals along
compartment dividers,
providing instant access to
mounting boxes, with no
drilling or cutting.
PART M
Compliance to
Part M building
regulations can
be achieved using
Part M !ange or
charcoal devices.
