Rating
External Dimensions
Order No
Amps
H x W x D (mm)
Integral Incoming Meter Kits
250A
3ph 4w CT Operated Energy Meter
400A
3ph 4w CT Operated Energy Meter
8GP1 921-4DA70
8GP1 921-6DA70
1
048
4.0
1
048
10.5
1
048
11.5
1
048
12.0
1
048
13.0
1
048
14.0
1
048
17.0
Cableways (with meter knock-outs)
available k/o's
3 mod
228 250 180
-
12 mod
912 250 180
6
13 mod
988 250 180
6
14 mod
1064 250 180
6
15 mod
1140 250 180
6
17 mod
1292 250 180
8
19 mod
1444 250 180
9
8GP1 914-0DA07
8GP1 914-0DA34
8GP1 914-0DA08
8GP1 914-0DA10
8GP1 914-0DA13
8GP1 914-0DA20
8GP1 914-0DA23
1
048
2.16
1
048
2.30
Integral Incoming MID Meter Kits
250A
3ph 4w CT Operated MID Energy Meter
400A
3ph 4w CT Operated MID Energy Meter
8GP1 991-4DA70
8GP1 991-6DA70
1
048
3.5
1
048
4.75
1
048
4.75
Integral Overvoltage Protection Kits
Contains: Digital meter offering amps, volts, kWh readout plus
pulsed output, ct or (3 ct's-MID), fuses, mounting plates &
cable looms.The latter supplied loose for connection by others
Contains: Lightning, Surge or Combination Arrester, mccb,
mounting plate & cable loom.The latter supplied loose for
connection by others. Please note: Only one of the integral
Lightning/Surge Arrester options is possible per panelboard with
mccb mounted in bottom right hand position.
Combination Lightning & Surge Arrester Kit, types 1 & 2
Lightning Arrester Kit, type 1
Surge Arrester Kit, type 2
8GP1 914-0DA14
8GP1 914-0DA15
8GP1 914-0DA16
1
048
2.00
1
048
2.00
Outgoing Meter Kits *
Contains: Digital meter offering amps, volts, kWh readout plus
pulsed output, ct or (3 ct's-MID), fuses, terminals, mounting plates
& cable looms.The latter supplied loose for connection by others
* Each bank of Outgoing Meter Kits require a:
63A
3ph 4w CT Operated Energy Meter
125A
3ph 4w CT Operated Energy Meter
8GP1 923-0DA70
8GP1 925-2DA70
1
048
1.68
Outgoing MID Meter Kits *
125A
3ph 4w CT Operated MID Energy Meter
8GP1 918-2DA70
1
048
Meter Pack Voltage Supply Cable Loom
8GP1 925-0DA10
Application
Integral meter ct internal dims info:
• 250A - 21mmWx25mmH slot
• 250A MID - 28mm dia
• 400A Std & MID - 31mmWx36mmH slot
Outgoing meter ct internal dims info:
• 63A & 125A - 16mmWx31mmH slot
• 125A MID - 21mm dia
• Rated Voltage: 400V 3ph 50Hz 4w
Integral & Outgoing Meter Kits
Panelboards
ALPHA BS III 125
2.3
Siemens IC LMV LV : 2012
2
Selection and ordering data
