22 / 40
List
Pack
Price
Weight
Price
Unit
Group 1 item (kg)
1
048
32.0
1
048
40.0
1
048
42.1
1
048
49.0
1
193
0.320
1
193
0.280
1
193
0.280
1
193
0.680
1
193
0.680
1
193
0.100
NGG Outgoing External Dimensions Modular
Order No
Ways
H x W x D (mm)
Height
250A Panelboard c/w TP Incoming Switching Unit*
Fault Rating: 25kA Conditional (Icc). Max 150mm² 4c incoming Cu cable
6 way
912 630 164
12
8 way
988 630 164
13
12 way
1140 630 164
15
16 way
1292 630 164
17
8GP1 506-1DA00
8GP1 508-1DA00
8GP1 512-1DA00
8GP1 516-1DA00
1
193
0.284
1
193
0.284
1
193
0.219
Incomer Overcurrent Release & Switch Disconnector Modules
* The switching unit must be fitted with either an
Overcurrent Release or Switch Disconnector module
160A 63A - 160A Overcurrent Release
250A 100A - 250A Overcurrent Release
250A 250A Switch Disconnector module
3VT9 216-6AC00
3VT9 225-6AC00
3VT9 225-6DT00
1
048
24.5
1
048
32.5
1
048
34.0
1
048
41.5
250A TP&N Direct Connect Incomer
Fault Rating: 25kA Conditional (Icc). M8 Connection on 25mm wide copper
Terminal extensions for TP incomers (1 per pole required)
6 way
912 630 164
12
8 way
988 630 164
13
12 way
1140 630 164
15
16 way
1292 630 164
17
8GP1 506-1DA02
8GP1 508-1DA02
8GP1 512-1DA02
8GP1 516-1DA02
1
048
0.01
NGG Door Blank
SP Door Blank with busbar insulator
8GP1 914-0DA00
Max cable
Cable Conn
csa
Type
Box Terminal
16…150mm²
Cu/Al
Terminals for circular conductors
25…150mm²
Cu/Al
150…240mm²
Cu/Al
2x25…150mm²
Cu/Al
2x150…240mm²
Cu/Al
6x6…35mm²
Cu/Al
3VT9 200-4TC00
3VT9 215-4TD00
3VT9 224-4TD00
3VT9 215-4TF00
3VT9 224-4TF00
3VT9 203-4TF00
Technical data:
Features:
• 250A & 400A rated Panelboards
• 25kA Fault rated
• Type Tested & ASTA Certified to IEC 61439-2
• Rated Voltage 230V/400V 3ph 50Hz
• Form 3b type 2 construction
• Up to 18 outgoing TP ways (16+2)
• Degree of Protection: IP3X
• Light grey paint finish: RAL7035
• User defined Incomer fitted as standard
• Integral Incoming Meter facility available as std
• Integral Lightning/ Surge Arrester available as std
• RoHS Compliant
2.1
2
250A Busbar System
Panelboards
ALPHA BS III 125
Front connection bars for increased spacing
1
193
0.490
1
193
0.628
3VT9 200-4ED30
3VT9 200-4EE30
50mm centres
-
Cu/Al
70mm centres
-
Cu/Al
Selection and ordering data
Siemens IC LMV LV : 2012
