28 / 40
1
048
61.5
1
048
67.2
1
048
73.0
Outgoing
External Dimensions
Order No
Ways
H x W x D (mm)
400A Panelboard Main Unit c/w TP Switching Unit*
Fault Rating: 35kA, 1 sec. Max cable lug connection: 32mm wide
2 way
1050 900 250
4 way
1155 900 250
6 way
1260 900 250
8GP1 402-6DA43
8GP1 404-6DA43
8GP1 406-6DA43
1
048
58.5
1
048
65.5
1
048
71.5
400A Panelboard Main Unit c/w 4P Switching Unit with Protected Neutral*
Fault Rating: 35kA, 1 sec. Max cable lug connection: 32mm wide
2 way
1050 900 250
4 way
1155 900 250
6 way
1260 900 250
8GP1 402-6DA53
8GP1 404-6DA53
8GP1 406-6DA53
1
048
1
048
Door Blanks
SP Door Blank - with busbar insulators
TP Door Blank - with busbar insulators
8GP1 914-0DA00
8GP1 978-0DA40
1
193
0.261
1
193
0.318
1
193
0.252
Incomer Overcurrent Release & Switch Disconnector Modules for TP Switching Units
* The switching unit must be fitted with either an
Overcurrent Release or Switch Disconnector module
*The switching unit must be fitted with an Overcurrent Release module
250A
100A - 250A Overcurrent Release
400A
160A - 400A Overcurrent Release
400A
Switch Disconnector module
3VT9 325-6AC00
3VT9 340-6AC00
3VT9 363-6DT00
1
193
0.355
1
193
0.355
Incomer Overcurrent Release for 4P Switching Units
250A
100A - 250A Overcurrent Release
400A
160A - 400A Overcurrent Release
4P Switch Disconnector module on request
3VT9 325-6BC00
3VT9 340-6BC00
1
048
1
048
1
048
400A NGG Extension Units
Fault Rating: 25kA, 1 sec
4 way
265 900 250
8 way
420 900 250
12 way
580 900 250
8GP1 914-0DA41
8GP1 914-0DA42
8GP1 914-0DA43
1
048
36.0
400A 3VT2 Extension Unit
Fault Rating: 35kA, 1 sec
8 way
580 900 250
8GP1 912-6DA43
Technical data:
Features:
• 400A & 630A rated Panelboards
• 35kA & 50kA Fault rated
• Type Tested & ASTA Certified to IEC 61439-2
• Rated Voltage 230V/400V 3ph 50Hz
• Form 3b type 2 construction
• Up to 18 outgoing TP ways (6+12)
• Degree of Protection: IP3X
• Light grey paint finish: RAL7035
• User defined Incomer fitted as standard
• Integral Incoming Meter facility available as std
• Integral Lightning/ Surge Arrester available as std
• RoHS Compliant
400A Busbar System
1
193
0.580
1
193
0.400
1
193
0.370
1
193
0.500
1
193
0.960
1
193
0.500
Terminal extensions forTP or 4P incomers (1 per pole required)
Max cable
Cable Conn
csa
Type
Box Terminal
35...240mm²
Cu/Al
Terminals for circular conductors
25…150mm²
Cu/Al
150…240mm²
Cu/Al
2x25…150mm²
Cu/Al
2x150…240mm²
Cu/Al
6x6…35mm²
Cu/Al
3VT9 300-4TC00
3VT9 315-4TD00
3VT9 324-4TD00
3VT9 315-4TF00
3VT9 324-4TF00
3VT9 303-4TF00
2.7
Siemens IC LMV LV : 2012
2
Selection and ordering data
List
Pack
Price
Weight
Price
Unit
Group 1 item (kg)
Panelboards
ALPHA BS III 250
