30 / 40
1
048
5.4
1
048
5.4
Rating
Order No
Amps
Integral Incoming Meter Kits
400A
3ph 4w CT Operated Energy Meter
630A
3ph 4w CT Operated Energy Meter
8GP1 921-6DA10
8GP1 921-7DA10
1
048
5.4
1
048
5.4
Integral Incoming MID Meter Kits
400A
3ph 4w CT Operated Energy Meter
630A
3ph 4w CT Operated Energy Meter
8GP1 991-6DA10
8GP1 991-7DA10
1
048
7.3
1
048
7.5
1
048
5.2
Integral Overvoltage Protection Kits
Contains: Digital meter offering amps, volts, kWh readout plus
pulsed output, ct, fuses, mounting plates & cable looms.The
latter supplied loose for connection by others
Contains: Lightning, Surge or Combination Arrester, mccb,
mounting plate & cable loom.The latter supplied loose for
connection by others. Please note: Only one of the integral
Lightning/Surge Arrester options is possible per panelboard
with mccb mtd in bottom left hand 3VT2 position.
Combination Lightning & Surge Arrester Kit, types 1 & 2
Lightning Arrester Kit, type 1
Surge Arrester Kit, type 2
8GP1 927-0DA10
8GP1 926-0DA10
8GP1 928-0DA10
1
048
1.75
1
048
1.75
1
048
1.80
1
048
1.80
Outgoing Meter Kits *
Contains: Digital meter offering amps, volts, kWh readout plus
pulsed output, 3 ct's, fuses, mounting plates & cable looms.
The latter supplied loose for connection by others
* Each bank of Outgoing Meter Kits require a:
63A
3ph 4w CT Operated Energy Meter
125A
3ph 4w CT Operated Energy Meter
160A
3ph 4w CT Operated Energy Meter
250A
3ph 4w CT Operated Energy Meter
8GP1 923-0DA10
8GP1 925-2DA10
8GP1 922-0DA10
8GP1 925-4DA10
1
048
1.70
1
048
1.65
1
048
1.70
Outgoing MID Meter Kits *
125A
3ph 4w CT Operated Energy Meter
160A
3ph 4w CT Operated Energy Meter
250A
3ph 4w CT Operated Energy Meter
8GP1 918-2DA10
8GP1 917-0DA10
8GP1 918-4DA10
1
048
0.60
Meter Pack Voltage Supply Cable Loom
8GP1 925-0DA10
Application
Features:
Integral meter current transformer cable connection info:
• 400A - 30mmx10mm copper bar - M10 connection
• 630A - 30mmx10mm copper bar - M10 connection
Outgoing meter ct internal dims info:
• 63A & 125A - 16mmWx31mmH slot
• 160A & 250A - 21mmWx25mmH slot
• MID Versions: 125/160 = 21mm dia
250 = 28mm dia
• Suitable for balanced or unbalanced loads
• Standard or MID meter kit options available
• Lightning or Surge Arrester options available
• Rated Voltage: 400V 3ph 50Hz 4w
Integral & Outgoing Meter Kits
2.9
Siemens IC LMV LV : 2012
2
Selection and ordering data
List
Pack
Price
Weight
Price
Unit
Group 1 item (kg)
Panelboards
ALPHA BS III 250
