BETA Monitoring

Monitoring of Plants and Devices

14/26

Siemens ET B1 · 10/2008

*

You can order this quantity or a multiple thereof.

14

Overview

The p.f. controllers monitor the phase displacement between

current and voltage. Because the phase displacement angle

changes with the load of the motor, this measurement method is

ideal for the monitoring of asynchronous motors for underload

and no-load operation, independent of size. However, in some

cases, the p.f. barely changes if the load of the motor changes,

e.g. in the case of relatively minor load changes on large-scale

motors or single-phase split-pole motors or collector motors.

The p.f. controller monitors single and three-phase asynchronous

motors up to approx. 5 A (without current transformer) for underload

and no-load operation. This is phase-sequence independent and

increases plant availability. Typical applications are fan monitoring

in the case of V-belt breakage, pump monitoring in the event of

valve closure or dry runs. A current transformer is used for

higher rated currents.

If the p.f. value set at the p.f. controller is fallen below for the

duration of the set response delay, the output relay switches to

the alarm state and the red LED lights up. If it exceeds the p.f.

value, the output relay switches back without any significant

delay.

Adjustable p.f. response value, from 0 to 0.97

Current range up to 8 A

LED display for operation and alarm

Automatic resetting of alarm.

Benefits

The ultra compact p.f. controller requires only the smallest of

spaces and saves costs.

Technical specifications

Selection and ordering data

5

TT3 472

Standards

IEC/EN 60255, VDE 0435

Rated control voltage U

c

3

V AC 400

Operating range

With AC supply

×

U

c

0.8 ... 1.1

Frequency range f

n

Hz

45 ... 65

Rated power dissipation P

v

VA

Approx. 11

Rated impulse withstand voltage U

imp

Against contacts

kV

< 4

Current measuring circuits

For AC systems

Current measuring range

I

meas

A AC 0.4 ... 8

Short-time overload capability

For 2 s

A

20

For 0.5 s

A

40

Current transformer

,

Class 3 or better

Secondary current

A

1

or 5

Setting ranges

Adjustable

p.f.

0 ... 0.97

Response delay

Adjustable

s

1 ... 100

Short-circuit strength

Fuse 4 A gL

A

4

Contacts

contact

1

CO

Rated operational voltage U

e

V AC 250

Rated operational current

I

e

Thermal current

A

4

AC-15 NO contacts

A

3

AC-15 NC contacts

A

1

AC-13 at 24 V DC

A

1

Minimum contact load

V; mA 10; 100

Terminals

Terminals

±

screw (Pozidriv)

PZ 2

Conductor cross-sections

-

Rigid

Max.

mm

2

2

× 2.5

-

Flexible, with end sleeve

Min.

mm

2

1

× 0.5

Permissible ambient temperature

°C

-20 ...

+60

Resistance to climate

Acc. to EN 60068-1

20/60/4

Degree of protection

Acc. to EN 60529

IP20, with connected conductors

Contacts

U

e

I

e

U

c

MW DT Order No.

Price

per PU

PG PU PS*/

P. unit

Weight

per PU

approx.

V AC A AC V AC

Unit(s) Unit(s) kg

p.f controllers

For monitoring of the underload of motors

up to approx. 5 A AC by making

p.f. measurements,

setting range p.f. from 0 to 0.97

1

CO 4

3

× 400 0.4 ... 8 1 B

5

TT3 472

027 1

1

0.065

5

TT3 472 p.f. controllers
