BETA Protecting

Overvoltage Protection Devices

Surge arresters, type 2

6/8

Siemens ET B1 · 10/2008

6

*

You can order this quantity or a multiple thereof.

Multipole surge arresters, narrow design

5

SD7 422-0 5SD7 422-1 5SD7 423-0 5SD7 423-1 5SD7 424-0 5SD7 424-1

Standards

IEC 61643-11; VDE 06754-6

Approved acc. to

KEMA KEMA/UL/

CUL

KEMA KEMA/UL/

CUL

KEMA KEMA/UL/

CUL

Rated voltage U

N

V AC 240

240/415

240/415

Rated arrester voltage U

C

L/N or L/PEN

V AC 350

350

350

N/PE

V AC 264

--

264

Rated discharge surge current

I

n

(8/20

s)

L/N or L/PEN, 1P/3P

kA 20

20

20

N/PE

kA 20

--

20

Discharge surge current

I

Imp

(8/20

s)

L/N or L/PEN, 1P/3P

kA 40

40

40

N/PE

kA 40

--

40

Protection level U

p

L/N or L/PEN

kV

1.4

1.4

1.4

N/PE

kV

1.5

--

1.5

Response time t

A

L/N

ns

25

25

25

N/PE

ns

100

--

100

Required back-up fuse, max.

A

125

gL

125

gL

125

gL

Short-circuit strength

with max. back-up fuse

kA

rms

25

25

25

Temperature range

°C -40 ... +80

Degree of protection

IP20, with connected conductors

Conductor cross-section

Finely stranded

mm

2

1.5 ... 16

Solid

mm

2

1.5 ... 25

Mounting width

Acc. to DIN 43880 mm 26

38

50

Visual function/fault indication

Yes

Remote signaling contact

Remote signaling (RS)

Yes

Contact type

Floating CO contact (plug-in)

Operational voltage, max.

V AC 250

V DC 125

Operational current, max.

-

Resistive/inductive load

A AC 1/1

-

Resistive/inductive load

mA DC 200/30

Conductor cross-section

-

Finely stranded

mm

2

1.5

-

Solid

mm

2

1.5
