BETA Protecting
Low-Voltage Fuse Systems
DIAZED fuse systems
3/19
Siemens ET B1 · 10/2008
3
*
You can order this quantity or a multiple thereof.
■
Dimensional drawings
DIAZED fuse links
Size
Thread
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
Unit(s) Unit(s) kg
DIAZED cover rings
Ceramic DII and DIII, also for EZR bus-mounting base
NDz
E16
C
5
SH3 30
016 1
5
0.020
DII
E27
B
5
SH3 32
016 1
10 0.029
DIII
E33
B
5
SH3 34
016 1
10 0.035
Made of molded plastic, also for EZR bus-mounting base
DII
E27
A
5
SH3 401
016 1
5/60 0.013
DIII
E33
A
5
SH3 411
016 1
5/60 0.014
5
SA1, 5SA2
Size/thread
TNDz/E16, NDz/E16
Rated current in A
2
4
6
10
16 20
25
Dimension d
6
6
6
8
10 12
14
49
I2_06251b
Ø13,2
Ød
5
SB1, 5SB2
Size/thread
DII/E27
Rated current in A
2
4
6
10
16 20
25
Dimension d
6
6
6
8
10 12
14
I2_06247b
Ød
49
Ø22,5
5
SB3, 5SB4
Size/thread
DIII/E33
Rated current in A
32
35
50
63
Dimension d
16
16
18
20
49
I2_06248b
Ød
Ø28
5
SC1, 5SC2
Size/thread
DIV/R1¼"
Rated current in A
80
100
Dimension d
5
7
Ø34,5
Ød
I2_06682a
57
5
SD6, 5SD8
Size/thread
DIII/E33
Rated current in A
2 4 6 10 16 20 25 35 50 63
Dimension d
6 6 6 8 10 12 14 16 18 20
70
I2_06329b
Ød
Ø28
