BETA Protecting
Low-Voltage Fuse Systems
DIAZED fuse systems
3/17
Siemens ET B1 · 10/2008
3
*
You can order this quantity or a multiple thereof.
1)
Can also be used with 690 V AC/600 V DC.
Size U
n
I
n
Thread Terminals DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
V AC/V DC A
Unit(s) Unit(s) kg
DIAZED components 750 V
DIAZED fuse bases
1
P, for screw fixing,
with fine thread and cap
DIII
750/750
63
E33S KK
A
5
SF4 230
016 1
1
0.460
DIAZED screw caps
made of ceramic, with fine thread
DIII
750/750
63
E33S
A
5
SH1 161
016 1
5
0.084
DIAZED EZR bus-mounting bases
1
P, to snap onto EZR busbars
for screw fixing
DII
500/500
25
E27
B
B
5
SF6 005
016 1
5
0.072
DIII
500/500
63
E33
B
B
5
SF6 205
016 1
5
0.135
DIAZED screw caps
Ceramic
NDz 500/500
25
E16
A
5
SH1 11
016 1
5/200 0.016
Molded plastic, with inspection hole, black,
not for SILIZED fuse links
DII
500/500
25
E27
}
5
SH1 221
016 1
5/200 0.026
DIII
1)
63
E33
}
5
SH1 231
016 1
5/5000 0.042
Ceramic
DII
500/500
25
E27
}
5
SH1 12
016 1
30
0.034
DIII
1)
63
E33
}
5
SH1 13
016 1
30
0.059
Ceramic, with inspection hole, sealable
DII
500/500
25
E27
A
5
SH1 22
016 1
30
0.050
DIII
1)
63
E33
A
5
SH1 23
016 1
30
0.076
Ceramic
DIV 500/500
100
R1¼"
C
5
SH1 141
016 1
1
0.181
Ceramic, prolonged version
DIII
690/600
63
E33
A
5
SH1 170
016 1
5
0.086
