Circuit-breakers, switch-disconnectors
Construction size 1: accessories
2010 CA08103002Z-EN
www.eaton.com17/197
Construction size 1:accessories
Residual-current relays
PFR-003
PFR-03
PFR-5
Ring-type transformer
PFR-W-20…30
PFR-W-35...210
Mounting clip
Magnetic shielding
PFR-WC
PFR-WMA
Earth-fault release
NZM1(-4)-XFI...R
NZM1(-4)-XFI...U
5 6 7 8
1 2 3 4
68
44
36
73
45
67
85
Fixing onTH35 top-hat rail to
IEC/EN 60715
G
H
J
I
F
B
33
46
C
D
A
E
F
6.5
Part no.
F
G H I
J
PFR-W-20 32 60 24 46 21
PFR-W-30 32 70 30 59 30
A B C D E
F
PFR-W-35 100 79 26 48.5 35 35
PFR-W-70 130 110 32 66 70 52
PFR-W-105 170 146 38 94 105 72
PFR-W-140 220 196 48.5 123 140 97
PFR-W-210 299 284 69 161 210 141
51.7
32.7
6.0
12.5
o
B
o
C
A1
A2
A
Part no.
A B C A1
A2
PFR-WMA-35
91 28 40 35
28
PFR-WMA-70
105 62 75 35
35
PFR-WMA-105 153 98 110 35
60
PFR-WMA-140 153 133 145 35
60
PFR-WMA-210 153 203 215 35
60
135
105
68
45
42.5
80.1
220
145
220
145
120
145
90.15
145
23.1
45
42.5
68
80.1
NZM1...-XFI..., PFR-...
