Circuit-breakers, switch-disconnectors

Construction size 1: accessories

2010 CA08103002Z-EN

17/195

Construction size 1:accessories

Mechanical interlock

NZM1-XMV + NZM1-XDV(R)

NZM1-XMV + NZM1-XTVD(V)(R)

NZM1-XMV + NZM1-XTVD(V)(R)-60

NZM1-XMV + NZM1-XTVD(V)(R)-0

① Special tip

90

120

45

40

40

143

5

7

29.2

80.3

45

22.5

51

31 27

NZM1/2-XV4 (NZM1/2-XV6)

245 – 400 (400 – 600)

Part no.

x

NZM1/2-XV4

245 – 400

NZM1/2-XV6

400 – 600

202 – 245

NZM1/2-XV...

163 – 202

a

NZM1-XMV, NZM1-XTV...
