Safety relays Safety 13/3
Basic device
ES4P… 1
Expandable: standard inputs/outputs
and standard bus systems
Bus system easyNet on board
24 V DC
14 safe digital inputs
4 safe relay outputs or
1 safe redundant relay output and
4 safe transistor outputs
Display and keypad optional
Bolt-on and top-hat rail mounting
Screw terminals
￫Page 13/5
Remote text display 2
Consists of:
• display/operating unit MFD-80(-B)
• power supply/communication
module
Including connecting cable
(can be cut to desired length, 5 m)
24 V DC = MFD-CP4-800
100 - 240 V AC = MFD-AC-CP4-800
Spring-loaded terminals
￫Page 13/7
Bus modules
EASY204-DP 3
PROFIBUS DP slave interface,
24 V DC
￫Page 13/6
EASY205-ASI 4
AS-Interface slave,
24 V DC
￫Page 13/6
EASY221-CO 5
CANopen interface, 24 V DC
￫Page 13/6
EASY222-DN 6
DeviceNet interface, 24 V DC
￫Page 13/6
Output expansion
EASY202-RE 7
2 relay outputs (max. 10 A, UL)
Bolt-on and top-hat rail mounting
Screw terminals
￫Page 13/6
I/O expansions
EASY6... 8
24 V DC
12 digital inputs
6 relay outputs (max. 10 A, UL) or
8 transistor outputs
Bolt-on and top-hat rail mounting
Screw terminals
￫Page 13/6
Coupling module 9
EASY200-EASY
For remote connection of a digital
I/O expansion through two-pole
connection cable
(max. 30 m); e.g. NYM 3 × 1.5 mm2
￫Page 13/6
800 10
Expandable: digital and analog inputs/
outputs and AS-Interface, CANopen,
PROFIBUS-DP, DeviceNet
Bus system easyNet on board
24 V DC = easy...DC...
100 - 240 V AC = easy...AC...
12 digital inputs
4 usable as analog inputs (DC versions)
6 relay outputs (max. 10 A, UL) or
8 transistor outputs
1 analog output, optional in DC models
Display and keypad optional
Bolt-on and top-hat rail mounting
Screw terminals
￫Page 12/14
Compact PLCControl 11
EC4P
￫Page 14/64
MFD-Titan Multi?Function?Display 12
￫Page 12/22
