www.eaton.comDS7 soft starters
Assigned switching and protective elements
Soft starter function with soft stop in case of overload
Mains contactor
Semiconductor protection (optional, fuse required for type 2
coordination in addition to cable protection for type 1
coordination)
5)
Cable protection
2)
Overload relays
3)
optional
4)
Fuses
Fuse holders
Type “1” coordination
Number x Part no.
Number x Part no.
PKM0-4 (+ CL-PKZ0)
ZB12-4
DILM7
3
× 50.179.06-16
3
x 51.060.04
PKM0-10 (+ CL-PKZ0)
ZB12-10
DILM9
3
× 50.140.06-25
3
x 51.060.04
PKM0-10 (+ CL-PKZ0)
ZB12-10
DILM9
3
× 20.282.20-32
3
x 21.189.01
PKM0-12 (+ CL-PKZ0)
ZB12-12
DILM12
3
× 20.282.20-32
3
x 21.189.01
PZM0-16 (+ CL-PKZ0)
ZB32-16
DILM17
3
× 50.140.06-50
3
x 51.060.04
PZM0-25 (+ CL-PKZ0)
ZB32-24
DILM25
3
× 50.140.06-63
3
x 51.060.04
PZM0-32 (+ CL-PKZ0)
ZB32-32
DILM32
3
× 50.140.06-80
3
x 51.060.04
NZMN1-M50 / PKZM4-50
ZB65-40+ZB65-XEZ
DILM50
3
× 50.140.06-80
3
x 21.189.01
NZMN1-M63 / PKZM4-58
ZB65-57+ZB65-XEZ
DILM65
3
× 20.282.20-125
3
x 21.189.01
NZMN1-M80
ZB150-70/KK
DILM80
3
× 20.610.32-200
3
x 21.313.02
NZMN1-M100
ZB150-100/KK
DILM95
3
× 20.610.32-200
3
x 21.313.02
NZMN1-M100
ZB150-100/KK
DILM115
3
× 20.610.32-200
3
x 21.313.02
NZMN2-M160
ZB150-150/KK
DILM150
3
× 20.610.32-350
3
x 21.313.02
NZMN2-M200
Z5-160/FF250
DILM185
3
× 20.610.32-400
3
x 21.313.02
NZMN2-M200
Z5-220/FF250
DILM225
3
× 20.610.32-500
3
x 21.313.02
