9/30 DS7 soft starters
Assigned switching and protective elements
2010 CA08103002Z-EN
Assigned switchingandprotectiveelements
Assigned Rated operational current1) Part no. Soft starter function
Motor rating at Soft starters
(device to be selected)
400 V 480 V Motor Soft starters Cable Cable protection2)
P P Ie Ie Type “1” coordination
kWh HP A A
Soft starters for three-phase mains connection,
low operating frequency (5 s, 3 x Ie, 10 starts/h)
1.5 2 3.6 4 DS7-34xSX004N0-x PKZM0-4 (+ CL-PKZ0)
3 3 6.6 7 DS7-34xSX007N0-x PKZM0-10 (+ CL-PKZ0)
4 5 8.5 9 DS7-34xSX009N0-x PKZM0-10 (+ CL-PKZ0)
5.5 7.5 11.3 12 DS7-34xSX012N0-x PKZM0-12 (+ CL-PKZ0)
7.5 10 15.2 16 DS7-34xSX016N0-x PKZM0-16 (+ CL-PKZ0)
11 15 21.7 24 DS7-34xSX024N0-x PKZM0-25 (+ CL-PKZ0)
15 20 29.3 32 DS7-34xSX032N0-x PKZM0-32 (+ CL-PKZ0)
22 25 41 41 DS7-34xSX041N0-x NZMN1-M50 / PKZM4-50
30 30 55 55 DS7-34xSX055N0-x NZMN1-M63 / PKZM4-58
37 40 68 70 DS7-34xSX070N0-x NZMN1-M80
45 50 81 81 DS7-34xSX081N0-x NZMN1-M100
55 60 99 100 DS7-34xSX100N0-x NZMN1-M100
75 75 134 135 DS7-34xSX135N0-x NZMN2-M160
90 100 160 160 DS7-34xSX160N0-x NZMN2-M200
110 125 196 200 DS7-34xSX200N0-x NZMN2-M200
Notes 1)Rated operational current based on the load cycle specified here.
2)Indicates the circuit-breaker required for the indicated load cycle. At different duty cycles (operating frequency, overcurrent, overcurrent time,
duty factor), this value changes and must then be adapted accordingly.
3) An external overload relay is required if the main contacts are not to be disconnected in the event of an overload and a controlled soft stop is
desired instead.
4)A mains contactor is not required. Disconnection characteristics in accordance with VDE can only be ensured with the specified circuit-breaker.
5)The superfast semiconductor fuses protect the soft starters from motor-side short-circuits. This can not, however, prevent damage caused by
voltage peaks, for example through lightning strike.
