3/56 Sensors
E57 Premium Plus Series
2010 CA08103002Z-EN
Inductive Sensors
InductiveSensorsE57PremiumPlusSeriesTechnical data
InductiveSensorsE57PremiumPlusSeries
E57-L...L12A E57-L...L12T E57-S...L12A E57-S...L12T
General
Standards IEC/EN 60947-5-2 IEC/EN 60947-5-2 IEC/EN 60947-5-2 IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP67 IP67 IP67 IP67
Mechanical shock resistance g 30
Shock duration 11 ms
30
Shock duration 11 ms
30
Shock duration 11 ms
30
Shock duration 11 ms
Characteristic values
Temperature drift of Sn % 10 10 10 10
Switching hysteresis of Sn % 20 15 20 15
Rated operating voltage 20 - 250 V AC 6 - 48 V DC 40 - 250 V AC
20 - 250 V DC
6 - 48 V DC
Rated operational current Ie 250 500 500 500
Switching frequency Hz 20 800 20 800
Switching state indication LED Red Red Red Red
Function 2-wire 3-wire 2-wire 3-wire
Construction type
Design (outer dimensions) M12 x 1 M12 x 1 M12 x 1 M12 x 1
Material Stainless steel Stainless steel Stainless steel Stainless steel
E57-L...L18A E57-L...L18T E57-S...L18A E57-S...L18T E57-R...L18A E57-R...L18T
General
Standards IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP67 IP67 IP67 IP67 IP67 IP67
Mechanical shock resistance g 30
Shock duration 11 ms
Characteristic values
Temperature drift of Sn % 10 10 10 10 10 10
Switching hysteresis of Sn % 20 15 20 15 20 15
Rated operating voltage 40 - 250 V AC
20 - 250 V DC
6 - 48 V DC 40 - 250 V AC
20 - 250 V DC
6 - 48 V DC 20 - 250 V AC 6 - 48 V DC
Rated operational current Ie 250 500 500 500 500 500
Switching frequency Hz 20 500 20 500 20 500
Switching state indication LED Red Red Red Red Red Red
Function 2-wire 3-wire 2-wire 3-wire 2-wire 3-wire
Construction type
Design (outer dimensions) M18 x 1 M18 x 1 M18 x 1 M18 x 1 M18 x 1 M18 x 1
Material Stainless steel
E57-L...L30A E57-L...L30T E57-S...L30A E57-S...L30T
General
Standards IEC/EN 60947-5-2 IEC/EN 60947-5-2 IEC/EN 60947-5-2 IEC/EN 60947-5-2
Ambient temperature °C -25 - +70 -25 - +70 -25 - +70 -25 - +70
Protection type IP67 IP67 IP67 IP67
Mechanical shock resistance g 30
Shock duration 11 ms
30
Shock duration 11 ms
30
Shock duration 11 ms
30
Shock duration 11 ms
Characteristic values
Temperature drift of Sn % 10 10 10 10
Switching hysteresis of Sn % 20 15 20 15
Rated operating voltage 20 - 250 V AC 6 - 48 V DC 40 - 250 V AC
20 - 250 V DC
6 - 48 V DC
Rated operational current Ie 250 500 500 500
Switching frequency Hz 20 300 20 300
Switching state indication LED Red Red Red Red
Function 2-wire 3-wire 2-wire 3-wire
Construction type
Design (outer dimensions) M30 x 1.5 M30 x 1.5 M30 x 1.5 M30 x 1.5
Material Stainless steel Stainless steel Stainless steel Stainless steel
Notes Further technical data can be found in the Online Catalogue at
