WARWI CK
ANC I L L ARY I T EMS AND S PAR E S
3
QUICK GUIDE TO FIVE PVC PROFILES
WARWICK 1 WARWICK 2 WARWICK 3 WARWICK 4 WARWICK 5
Ref No
Ref No
Ref No
Ref No
Ref No
Trunking Pack
BCL1
BCL2
BCL3
BCL4
BCL5
Internal Bend
BCL1/IB BCL2/IB BCL3/IB BCL4/IB BCL5/IB
External Bend
BCL1/EB BCL2/EB BCL3/EB BCL4/EB BCL5/EB
Flat Angle 90° (Downward)
BCL1/FAD BCL2/FAD BCL3/FAD BCL4/FAD BCL5/FAD
Flat Angle 90° (Upward)
–
BCL2/FAU
–
BCL4/FAU BCL5/FAU
Flat Tee (Downward)
BCL1/FTD BCL2/FTD BCL3/FTD BCL4/FTD BCL5/FTD
Flat Tee (Upward)
–
BCL2/FTU
–
BCL4/FTU BCL5/FTU
Stop End - Left
BCL1/SEL BCL2/SEL BCL3/SEL BCL4/SEL BCL5/SEL
Stop End - Right
–
BCL2/SER
–
BCL4/SER BCL5/SER
Coupler Pack
BCL1/CP BCL2/CP BCL3/CP BCL4/CP BCL5/CP
Angled Cable Retainer
BCL/ACR BCL/ACR
–
BCL/ACR
–
Standard Cable Retainer
BCL/SCR BCL/SCR BCL/SCR BCL/SCR BCL/SCR
Square Cable Retainer
–
BCL/SQCR BCL/SQCR BCL/SQCR BCL/SQCR
Single Gang Accessory Box
BCL/SGB BCL/SGB BCL/SGB BCL/SGB BCL/SGB
Twin Gang Accessory Box
BCL/TGB BCL/TGB BCL/TGB BCL/TGB BCL/TGB
SQUARE COVER SECTION
BCL/SCS
Pack Quantity 5 x 3m
MAIN COVER
BCL/MC
Pack Quantity 5 x 3m
ANGLED COVER SECTION
BCL/ACS
Pack Quantity 5 x 3m
CROSSOVER BRIDGE PIECE
BCL/CBP
Pack Quantity 5
FLUSH BACK BOX
BCL/FBB
Pack Quantity 1
BASE EXTENSION
BCL/BE
Pack Quantity 5 x 3m
METAL SCREENING
Should metal screening be required, aluminium
sections can be supplied for both top and bottom
sections of the trunking to ensure “spiking” does
not occur. If screened data/telephone cables are
being used within the wiring system internal metal
screening is not needed.
ANGLED SECTION SCREEN
BCL/ASS
Supplied in 1m lengths
SQUARE SECTION SCREEN
BCL/SSS
Supplied in 1m lengths
