WARWI CK
MODU L AR P VC RANGE
2
WARWICK 1
•
Base Unit
•
Angled Top and Bottom Covers
•
Main Centre Cover
See page 4
50
mm
170
mm
85
mm
42
mm
42
mm
WARWICK 2
•
Base Unit
•
Angled Top Cover
•
Main Centre Cover
•
Square Bottom Cover
See page 5
50
mm
170
mm
85
mm
42
mm
42
mm
WARWICK 3
•
Base Unit
•
Square Top and Bottom Covers
•
Main Centre Cover
See page 6
50
mm
170
mm
85
mm
42
mm
42
mm
WARWICK 4
•
Base Unit
•
Base Extension
•
Angled Top Cover
• 2
x Main Covers
See page 7
212
mm
50
mm
85
mm
85
mm
42
mm
WARWICK 5
•
Base Unit
•
Base Extension
•
Square Top Cover
• 2
x Main Covers
See page 8
212
mm
50
mm
85
mm
85
mm
42
mm
For Bus-bar sections see pages 9 & 10
