8 / 413
1/2
Premium platforms for Unity Pro software offer
TSX 57 1
p
processors
Number of racks
(
according to rack type)
4
with 4, 6 or 8 slots or 2 with 12 slots
In-rack I/O
(1)
Discrete I/O
512
channels (8-, 16-, 32- or 64-channel module)
Analog I/O
24
channels (4-, 8- or 16- channel module)
In-rack application-
specific channels
Max. number of channels
8
Counter
Module with 2/4 counter channels 1 MHz max., single-channel electronic cam module
Motion
(2)
Modules with 1/2 axes for stepper motors, 2/3/4 axes for analog control servo motors, with 8/16
axes with SERCOS digital link
Weighing
Modules for 8 load cells (1 application-specific channel)
Serial links
TSX SCY in-rack communication modules (1 application-specific channel)
Serial link connections
Modbus
RS 232, RS 485 or current loop
(3)(4)
master/slave PCMCIAmodules and RS 485 in-rack
master/slave communication modules
Uni-Telway
1
integrated RS 485 master/slave channel
(5)
,
RS 232, RS 485 or current loop
(3)(4)
master/
slave PCMCIAmodules and RS 485 in-rack master/slave communication modules
Character mode
1
integrated RS 485 channel
(5)
,
RS 232, RS 485 or current loop
(3)
(
4)
PCMCIAmodules and
RS 485 master/slave in-rack communication modules
Bus connections
Actuator/sensor bus
AS-Interface master V2
2
in rack modules
CANopen machine bus
master V4.02
1
PCMCIAmodule
(3)
I
NTER
B
US
field bus master V2
(6)
or
Profibus DP field bus master V0
Class1 and 2
(6)
–
Network connections
Max. no. of networks
1
Ethernet
In-rack modules: Ethernet Modbus/TCP (Web server, FactoryCast server or FactoryCast HMI
server) and EtherNet/IP
Fipway/Ethway/Modbus Plus
modules
Modbus Plus
(3)
,
Fipway
(3)(4)
modules, Ethway “in-rack” modules
Integrated process
control
Configurable loops
–
Programmable loops
Process control EFB library
Hot Standby availability
–
Memory capacity
Without PCMCIA extension
96
Kb program and data
With PCMCIA extension
224
Kb program
96
Kb data
Data storage
256
Kb (PCMCIA extension in upper slot (0) on processor)
USB programming port
–
Power supply
100…240
V
a
, 24
V
c
non-isolated and 24…48 V
c
isolated power supply. A power supply is
required for each rack.
Consumption
See page 9/6
Standards and certifications
See pages 9/8 and 9/18
Premium processor
type
(12)
Standard
TSX P57 104M
Integrated Ethernet
(9)
TSX P57 1634M
Integrated CANopen
Integrated Fipio
TSX P57 154M
(11)
g
Pages
1/10
(1)
The maximum values for the numbers of discrete and analog I/O are cumulative (with the exception of
TSX H57 24M
/
44
M
Hot Standby processors).
(2) 1
axis = 1 application-specific channel, except for SERCOS modules where, depending on the configuration, the module = 2…32 channels.
(3)
Module to be inserted into the lower PCMCIA slot (no. 1) on a Premium processor.
(4)
Module to be inserted into the
TSX SCY 21 601
in-rack communication module slot.
(5)
Non-isolated serial link. For distances > 10 m, use connection accessory
TSX PACC 01
,
see pages 5/131 and 5/133.
(6)
The I
NTER
B
US
and Profibus DP limits are not cumulative.
g
Modicon Premium automation
platform
Premium processors
Unity
Selection Guide
