1/5

Description

Processors without integrated Ethernet Modbus/TCP port

TSX P57 1

p

4

M

single-format processors and

TSX P57 2

p

4

M/3

p

4

M

double-format

processors feature the following on the front panel:

1

A display block with 5 LEDs:

v

RUN LED (green): Processor in operation (program execution)

v

ERR LED (red): Fault on the processor or its on-board devices (PCMCIAmemory

card and PCMCIA communication card)

v

I/O LED (red): Faults occurring on another PLC station module or configuration

fault

v

TER LED (yellow): Activity on the TER or AUX terminal port

v

FIP LED (red): Activity on the integrated Fipio bus (depending on model)

2

ARESET button causing a cold start of the PLC when pressed.

3

An 8-way female mini-DIN connector marked TER for connecting a programming

or adjustment terminal (RS 485)

4

An 8-way female mini-DIN connector marked AUX for connecting a programming,

adjustment or operator dialogue terminal (RS 485)

5

A PCMCIA slot (no. 0) for a memory card.

6

A PCMCIA slot (no. 1) for a communication card or memory extension card for

storing additional data

7

A 9-way SUB-D connector (on

TSX P57 154M/254M/354M

models) for Fipio bus

communication (Fipio manager port)

8

An air recirculating heatsink (on

TSX P57 1

p

4

M

models)

Modicon Premium automation

platform

0

Unity processors

Presentation:

page 1/4

Memory structure:

pages 1/8 …

References:

pages 1/10 …

PCMCIA references:

pages 1/12 …

TSX P57 254M/354M

1

2

3

4

5

6

7

TSX P57 204M/304M

TSX P57 154M

TSX P57 104M

1

2

3

4

5

6

7

8

2

1

3

4

5

6

7

8

9

10
