Earth bonds & clamps
Type H high strength splitbolt connector
B
Conductor range
Main
Tap
Dimension
B
Weight
Part
each
No.
Min
Max
Min
Max
4 mm
2
10 mm
2
2.5 mm
2
10 mm
2
4.1 mm 0.02 kg
8H-FU
10 mm
2
16 mm
2
2.5 mm
2
16 mm
2
5.5 mm 0.03 kg
4H-FU
16 mm
2
25 mm
2
4 mm
2
25 mm
2
6.9 mm 0.04 kg
2H-FU
25 mm
2
35 mm
2
4 mm
2
35 mm
2
8.4 mm 0.06 kg
1H-FU
35 mm
2
50 mm
2
4 mm
2
50 mm
2
9.7 mm 0.09 kg
10H-FU
35 mm
2
70 mm
2
4 mm
2
70 mm
2
11.2 mm 0.14 kg
20H-FU
50 mm
2
95 mm
2
4 mm
2
95 mm
2
13.6 mm 0.17 kg
30H-FU
50 mm
2
120 mm
2
6 mm
2
120 mm
2
14.7 mm 0.18 kg
40H-FU
95 mm
2
185 mm
2
6 mm
2
185 mm
2
18.2 mm 0.35 kg
350M-FU
BS 7430
For copper to copper connections. No special tools required.
8H-FU
