Earth bonds & clamps
Stem diameter = 10.7 mm (70 mm 2).
Hole size Length Weight Part
each No.
M8 x 15 mm 80 mm 0.14 kg PC100-FU
M10 x 15 mm 80 mm 0.14 kg PC101
M12 x 15 mm 80 mm 0.14 kg PC102
M16 x 15 mm 80 mm 0.14 kg PC103
Single hole earth point with single pre-welded tail
Description Weight each Part No.
PC100-FU earth point with pre-welded 500 mm earth cable 0.56 kg PC105†
PC101 earth point with pre-welded 500 mm earth cable 0.56 kg PC106†
PC102 earth point with pre-welded 500 mm earth cable 0.56 kg PC107†
PC103 earth point with pre-welded 500 mm earth cable 0.56 kg PC108†
BS EN 50164-1 Class H, BS 7430
†UL96 (PC105, PC106, PC107, PC108)
Tightening torque 8 Nm
Single hole earth point
Earth points
Furse earth points are available for direct connection to conductors, or with additional pre-welded tail (single or
double 70 mm2 PVC insulated cable) to enable connection to internal rebar arrangements via mechanical clamps (see
product tables for individual product availability).
PC100-FU
