Earth bonds & clamps
Two hole earth point
Hole size Length Weight Part
each No.
M8 x 12 mm 80 mm 0.44 kg PC115-FU
Supplied c/w front plate for connection of 25 mm x 3 mm copper tape or 70 mm2
stranded copper cable.
M8 x 12 mm 80 mm 0.44 kg PC120
Supplied c/w front plate for connection of 25 mm x 3 mm copper tape or
8 mm diameter solid circular copper.
M8 x 12 mm 80 mm 0.28 kg PC125
Supplied without front plate.
Two hole earth point with single pre-welded tail
Description Weight each Part No.
PC115-FU earth point with pre-welded 500 mm earth cable 0.84 kg PC116†
PC120 earth point with pre-welded 500 mm earth cable 0.84 kg PC121†
PC125 earth point with pre-welded 500 mm earth cable 0.84 kg PC126-FU†
Two hole earth point with double pre-welded tail
PC115-FU earth point with pre-welded 2 x 500 mm earth cable 1.26 kg PC216†
PC120 earth point with pre-welded 2 x 500 mm earth cable 1.26 kg PC221
Hole size Length Weight Part
each No.
M8 x 14 mm 75 mm 0.41 kg PC110
Four hole earth point with single pre-welded tail
PC110 earth point with pre-welded 500 mm earth cable 1.14 kg PC111†
Four hole earth point with double pre-welded tail
PC110 earth point with pre-welded 2 x 500 mm earth cable 1.23 kg PC211†
Four hole earth point
Stem diameter = 10.7 mm (70 mm2).
BS EN 50164-1 Class H, BS 7430
†UL96 (PC116, PC121, PC126-FU, PC216)
Tightening torque 8 Nm
Stem diameter = 10.7 mm (70 mm2).
BS EN 50164-1 Class H, BS 7430
†UL96 (PC111, PC211)
Tightening torque 8 Nm
PC115-FU
PC125
PC110
