Conductors
TSC-0912 - 09.10.12
Conductor size
(X x Y)
Weight
per metre
Standard Part
coil size No.
25 x 3 mm 0.79 kg 25 m TC111-FU
25 x 3 mm 0.79 kg 50 m TC111/50
Green & yellow PVC insulated copper tape
High conductivity copper tape to BS EN 13601 (formerly BS 1432).
PVC colours to BS 6746C.
Cross-sectional
area
Stranding
No./mm Ø
Weight Part
per metre No.
16 mm 2 7/1.70 0.19 kg CC016
25 mm 2 7/2.14 0.29 kg CC025
35 mm 2 7/2.52 0.41 kg CC035
50 mm 2 19/1.78 0.53 kg CC050
70 mm 2 19/2.14 0.73 kg CC070
95 mm 2 19/2.52 1.00 kg CC095
120 mm2 37/2.03 1.16 kg CC120-FU
150 mm2 37/2.25 1.54 kg CC150-FU
185 mm2 37/2.52 2.01 kg CC185
240 mm2 61/2.25 2.49 kg CC240
300 mm2 61/2.52 3.05 kg CC300
400 mm2 61/2.85 3.90 kg CC400-FU
Green & yellow PVC insulated stranded copper cable
PVC covered soft drawn stranded copper cable to BS 6004.
PVC colours to BS 6746C.
TC111-FU
CC070
