Conductors
TSC-0912 - 09.10.12
Bare stranded copper cable
Soft drawn stranded copper cable to BS EN 60228.
Hard drawn stranded copper cable to BS 7884.
Cross-sectional
area
Stranding
No./ mm Ø
Nominal
diameter (A)
Weight Part
per metre No.
Soft drawn stranded copper cable
6 mm 2 7/1.04 3.12 mm 0.05 kg CB006
16 mm 2 7/1.70 5.10 mm 0.15 kg CB016
25 mm 2 7/2.14 6.42 mm 0.23 kg CB025
35 mm 2 7/2.52 7.56 mm 0.32 kg CB035
50 mm 2 19/1.78 8.90 mm 0.43 kg CB050-FU
70 mm 2 19/2.14 10.70 mm 0.62 kg CB070
95 mm 2 19/2.52 12.60 mm 0.86 kg CB095
120 mm2 37/2.03 14.21 mm 1.09 kg CB120
150 mm2 37/2.25 15.75 mm 1.33 kg CB150-FU
185 mm2 37/2.52 17.64 mm 1.67 kg CB185
240 mm2 61/2.25 20.25 mm 2.20 kg CB240
300 mm2 61/2.52 22.68 mm 2.76 kg CB300-FU
400 mm2 61/2.85 25.65 mm 3.53 kg CB400-FU
Tinned soft drawn stranded copper cable
70 mm 2 19/2.14 - 0.62 kg CB070-T*
Hard drawn stranded copper cable
70 mm 2 7/3.55 - 0.64 kg CB071*
* Additional sizes available on request.
High conductivity copper tape to BS EN 13601
(formerly BS 1432).
†UL96 (TC230-UL)
Conductor size
(X x Y)
Weight
per metre
Standard Part
coil size No.
12.5 x 1.5 mm 0.17 kg 100 m TC225-FU
25 x 3 mm 0.67 kg 50 m TC230
1” x 1⁄
8 ” 0.67 kg 50 m TC230-UL†
30 x 2 mm 0.53 kg 50 m TC239
25 x 6 mm 1.33 kg 40 m TC240
31 x 3 mm 0.83 kg 50 m TC245
38 x 5 mm 1.69 kg 30 m TC260
50 x 6 mm 2.68 kg 20 m TC280
Tinned copper tape
CB070
TC230
NEW
A
