FurseWELD
TSC-0912 - 09.10.12
Cable to steel surface & pipe CS25
A
A
* 1 x S103
* 1 x S103
A
mm2
16* 45P10 CS25-4-16 HCPK4 CS25-3-16 HCPK3
25 45P10 CS25-4-25 HCPK4 CS25-3-25 HCPK3
35 45P10 CS25-4-35 HCPK4 CS25-3-35 HCPK3
8 mm Ø 65P10 CS25-4-8SC HCPK4 CS25-3-8SC HCPK3
50 65P10 CS25-4-50 HCPK4 CS25-3-50 HCPK3
10 mm Ø 90P10 CS25-4-10SC HCPK4 - -
70 90P10 CS25-4-70 HCPK4 CS25-3-70 HCPK3
95 115P10 CS25-4-95 HCPK4 - -
120 115P10 CS25-4-120 HCPK4 - -
150 150P10 CS25-4-150 HCPK4 - -
185 200P10 CS25-4-185 HCPK4 - -
240 200P10 CS25-4-240 HCPK4 - -
300 250P10 CS25-4-300 HCPK4 - -
Cable to steel surface & pipe CS27
A
mm2
16* 45P10 CS27-4-16 HCPK4
25 45P10 CS27-4-25 HCPK4
35 45P10 CS27-4-35 HCPK4
8 mm Ø 65P10 CS27-4-8SC HCPK4
50 65P10 CS27-4-50 HCPK4
10 mm Ø 115P10 CS27-4-10SC HCPK4
70 115P10 CS27-4-70 HCPK4
95 150P10 CS27-4-95 HCPK4
120 150P10 CS27-4-120 HCPK4
150 200P10 CS27-5-150 HCPK5
185 250P10 CS27-5-185 HCPK5
240 2 x 150P10 CS27-5-240 HCPK5
300 2 x 200P10 CS27-5-300 HCPK5
Special moulds for all FurseWELD products can be manufactured to meet
specific customer applications on request.
