Cable to reinforcing bar
Cable to steel surface & pipe
Stud to steel surface SureSHOT
Furse, Wilford Road, Nottingham, NG2 1EB • Tel: +44 (0)115 964 3700 • Email: • Web:
Connection selector FurseWELD
TSC-0912 - 09.10.12
CRE3 Page 151 CRE6 Page 152 CRE1 Page 149 CRE2 Page 150-151 CRE17 Page 152
CS3 Page 154 CS7 Page 154 CS1 Page 153 CS2 Page 153 CS8 Page 155
CS27 Page 156 CS32 Page 157 CS9 Page 155 CS25 Page 156 CS34 Page 158
RS1 Page 159 RS2 Page 159 SS1 Page 161 SS2 Page 161
CR24 Page 148 CR17 Page 147 CR3 Page 146 CR1 Page 144 CR2 Page 145
Conductors must be in the orientation shown to achieve the correct connection. Furse offers technical support to
assist with selection of joint type. If connections shown do not meet your requirements, please contact your local sales
office on +44 (0)115 964 3700 (UK), +971 (0)4 609 1635 (Dubai) or +65 6720 8828 (Singapore) for assistance.
Cable to earth rod
